Common Data
Temp. sub ranges
Emissivity slope
Emissivity ε
Transmittance
Spot size fill factor
Switch-off level
Analog output signal
3 configurable
inputs / outputs
PROFIBUS
PROFINET
Ethernet
Peak picker
Display
Parameter settings
Power supply
Isolation
Sightings
(optional)
Storage
Relative humidity
Housing / protection
class
Weight
CE label
68 / 81
METIS M311 / M322 / H311 / H322 (12-pin device connector)
Any range adjustable within the temperature range (minimum span 50°C)
0.800–1.200
0.050–1.200 (corresponds 5–120% in 0.1% steps)
5–100% in 0.1% steps
5–100% in 0.1% steps
2–90%
2 scalable analog outputs 0 or 4–20 mA, switchable, max. load: 500 Ω.
Resolution 0.0015% of the adjusted sub range temperature (16 Bit).
User selectable: 2-color temperature, 1-color channel 1 or 1-color channel 2 temperature, de-
vice temperature or control output (if equipped with a controller)
Outputs can be scaled, inside or outside the temperature range.
▪ Digital inputs (max. 3 inputs, protected against reverse polarity): laser targeting light on/off,
clearing of peak picker, controller start (when equipped with PID controller), load pyrometer
configuration, and trigger input for start / stop of measured value recording.
▪ Digital outputs (max. 3 outputs, max. 50 mA, protected against short circuit): limit switch,
exceeding the beginning of temperature range (for material recognition), device ready after
self-test, device over-temperature, signal strength too low. When equipped with PID con-
troller: controller active, control process within limits, control process finished.
▪ Analog input (0–20 mA, protected against reverse polarity and incorrect connection): ana-
log adjustment of the emissivity, or setpoint for PID controller (devices with PID controller).
Supports PROFIBUS DP-V0 (and DP-V1) according to IEC61158 type 3
Supports PROFINET-RT and IRT according to specification 2.3. Pre-certified, supports class
A, B and C functionalities
Compliant with IEEE802.3/802.3u (Fast Ethernet) und Compliant with ISO 802-3/IEEE 802.3
(10BASE-T)
Automatic hold mode or manual time settings to clear (reset) or external clear (via configurable
input)
Devices with LED: 10-digit LED display (5 mm high) for temperature display or device settings
Devices with LED: Dot matrix, green-yellow, 128 x 32 Dots (5.6 mm high) for temperature dis-
play or device settings (to avoid premature aging of the OLED display, it is
darkened if no button is pressed for 10 minutes and from an internal tem-
perature of 60°C (140°F). The display is switched off from an internal de-
vice temperature of 75°C (167°F))
Resolution 0.1°C / °F
Push buttons on the device, serial interface, PC software SensorTools or via self-compiled
communication program:
Slope/ratio, switch-off limit for measurement, switch-off limit for dirty window alarm, emissivity,
transmission, fill factor, temperature sub range, settings for max. value storage, device ad-
dress, baud rate, response time, selecting analog outputs 0/4–20 mA, interface RS232/RS485
(selection on device only), °C/°F, language (English / German), measuring distance with mo-
torized focus optics.
24 V DC (18–30 V DC), protected against reverse polarity
Voltage supply, analog and digital output are galvanically isolated from each other
▪ Thru-lens sighting with adjustable attenuation filter for eye protection of bright targets
▪ Laser targeting light (red, λ=650 nm, P< 1 mW, laser class 2 to IEC 60825-1)
▪ Color CCD camera, field of view: ca. 3.6 x 2.7% of measuring distance
output signal: FBAS signal ca. 1 V
Resolution: NTSC: 720 x 480 Pixels; PAL: 720 x 576 Pixels
Storage temperature: -20 to 85°C (-4 to 185°F)
Relative humidity: max. 95%, no condensing conditions, do not store outdoors, protect from
direct sunlight, store dry and dust-free, do not exposed to corrosive media, avoid mechanical
vibrations
Non-condensing conditions
Aluminum, IP65 to DIN 40 050 with connector
Min. 660 g (1.46 lbs)
According to EU directives
, 75 Ω, CCIR, NTSC / PAL switchable
