You are advised to use a metal holder (not included in the package) for 2N
the USA. With the aid of this holder, the device can be installed into a universal US single-gang
mounting box. The device can also be installed directly onto a wall without a mounting box.

Tip
Drilling Template
1. Draw the pre-prepared LAN connector leading from the wall through the metal holder.
Make sure that it is properly oriented for device connection after mounting. If necessary,
align the holder using a level and drill it into the mounting box or on the wall. The wall
mounting screws are not part of the delivery, the included screws are only for the
mounting box installation.
2. Connect the LAN connector to the device.
3.
a. Put the device under the holder with its bottom edge first. Then put the device
vertically on the wall keeping the device bottom edge under the holder.
