On-Wall Installation - 2N Clip User Manual

3.2 On-Wall Installation

For on-wall mounting, install the flush mounting box first into which the device is subsequently
mounted.

Warning
Having unpacked 2N
hands at the same time to remove it safely. A careless removal and insufficient push
might lead to a locking latch damage. Hence, follow the mentioned metal holder
instructions below closely!
Here is what you can find in this section:
• 3.2.1 Flush Mounting Box Installation of Device
®
Clip, remove the metal holder for installation. Use both your
1. Push the locking latch in the center of the device
bottom edge with your left hand in such a manner that
it bends sufficiently for the metal holder removal. Do
not push the locking latch from the top. You might get
injured while removing the metal holder.
2. Grasp the metal holder with your right hand and slide it
downwards for removal.
2N® Clip User Manual
11 / 75
