3.3 Stand Installation

Alternatively, the device can be installed into a stand placed on a desk, for example. The stand is
not included in the package.
Within installation preparations, take out the pre-prepared cabling, UTP cable, doorbell (twin)
cable and power supply. Shorten the cables to the required length. Crimp the RJ-45 connector
onto the UTP cable. Connect the doorbell twin cable together with the LAN connector to the
connector.

Warning
Having unpacked 2N
hands at the same time to remove it safely. A careless removal and insufficient push
might lead to a locking latch damage. Hence, follow the mentioned metal holder
instructions below closely!
®
Clip, remove the metal holder for installation. Use both your
1. Push the locking latch in the center of the device
bottom edge with your left hand in such a manner that
it bends sufficiently for the metal holder removal. Do
not push the locking latch from the top. You might get
injured while removing the metal holder.
2. Grasp the metal holder with your right hand and slide it
downwards for removal.
