Ref. Qty. Description
27 1 RCA 4X2
CON011
28 5 MOMENTARY
SWT013
29 3 .05 45X2
CON019
30 2 DIP8 SWT016
31 1 DIP6 SWT017
32 7 DIP4 SWT018
33 1 DB9 9PIN DB9F
34 1 RCA RCA_1X2
CON031
35 4 IDC 2X1
IDC2X1
36 1 IDC 7X2
IDC7X2
37 1 IDC 10X2
IDC10X2
38 1 2.5A
RESETABLE
FUS001
39 1 IDC 2X2
IDC2X2
40 1 3.5MM
STEREO_JACK
CON001
41 1 IDC 13x2
IDC13x2
42 8 YELLOW
LED001
ADSP-21375 EZ-KIT Lite Evaluation System Manual
ADSP-21375 EZ-KIT Lite Bill of Materials
Reference Manufacturer
Designator
J5 SWITCHCRAFT
SW8-12 PANASONIC
J1-3 SAMTEC
SW1,SW14 C&K
SW13 CTS
SW2-7,SW15 ITT
J6 AMP/TYCO
J10 SWITCHCRAFT
JP1-4 FCI
ZP4 FCI
P3 FCI
F1 RAYCHEM
P11 FCI
J9 A/D ELEC-
TRONICS
P4 BERG
LED1-8 PANASONIC
Part Number
PJRAS4X2U01X
EVQ-PAD04M
SFC-145-T2-F-D-A
TDA08H0SB1
218-6LPST
TDA04HOSB1
5745781-4
PJRAS1X2S02X
90726-402HLF
68737-414HLF
68737-420HLF
SMD250F-2
68737-404HLF
ST-323-5
54102-T08-13LF
LN1461C
A-3
