Ref. Qty. Description
108 4 1UF 6.3V 20%
0402
109 6 100 1/16W 5%
0402
110 1 0.027UF 25V 5%
0603
111 2 0.27UF 16V 20%
0603
112 2 2.05K 1/16W 1%
0402
113 1 232.0 1/16W 1%
0603
114 2 301.0 1/16W 1%
0603
115 1 24.9K 1/10W 1%
0603
116 1 47UF 6.3V 10%
B
117 1 511.0 1/16W 1%
0402
118 1 0.05 1/2W 1%
1206
119 1 10UF 16V 10%
1210
120 1 GREEN LED001
121 1 RED LED001
122 1 255.0K 1/10W
1% 0603
ADSP-21375 EZ-KIT Lite Evaluation System Manual
ADSP-21375 EZ-KIT Lite Bill of Materials
Reference Manufacturer
Designator
C197-200 PANASONIC
R136-137, DIGI-KEY
R165-167,R179
C181 AVX
C180,C182 AVX
R100-101 VISHAY
R129 DIGI-KEY
R105-106 DIGI-KEY
R17 DIGI-KEY
CT5 PANASONIC
R135 DIGI-KEY
R16 SUSUMA
C3 AVX
LED9 PANASONIC
LED10 PANASONIC
R35 VISHAY
Part Number
ECJ-0EB0J105M
311-100JRTR-ND
06033C273JAT2A
0603YG274ZAT2A
CRCW04022K05FKED
311-232HRTR-ND
311-301HRTR-ND
311-24.9KHTR-ND
EEE0JA470WR
311-511LCT-ND
RL16326-R050-F-N
1210YD106KAT2A
LN1361CTR
LN1261CTR
CRCW06032553FK
A-9
