DAI Header (P4)
The DAI connector (
from of a .1" spacing header. When using the header to access the DAI
pins of the processor, ensure that signals, which normally drive the DAI
pins, are disabled. Refer to
more information on how to disable signals already being driven from
elsewhere on the EZ-KIT Lite.
Part Description
26-pin IDC header
JTAG Header (ZP4)
The JTAG header (
ZP4
emulator pod. When an emulator connects to the JTAG header, the USB
debug interface is disabled.

Pin 3 is missing to provide keying. Pin 3 in the mating connector
should have a plug.

When using an emulator with the EZ-KIT Lite board, follow the
connection instructions provided with the emulator.
Part Description
14-pin IDC header
ADSP-21375 EZ-KIT Lite Evaluation System Manual
ADSP-21375 EZ-KIT Lite Hardware Reference
) provides access to all of the DAI signals in the
P4
"Codec Setup Switch (SW3)" on page 2-11
Manufacturer
BERG
) is the connecting point for a JTAG in-circuit
Manufacturer
FCI
for
Part Number
4102-T08-13LF
Part Number
68737-414HLF
2-25
