A ADSP-21375 EZ-KIT LITE BILL
OF MATERIALS
The bill of materials corresponds to
matic" on page B-1.
Ref. Qty. Description
1 1 74LVC14A
SOIC14
2 1 IDT74FCT3244
APY SSOP20
3 1 12.288MHZ
OSC003
4 1 LT1765 SOIC8
5 1 GTL2002
TSSOP8
6 1 LTC1877
MSOP8
7 3 SN74LVC1G08
SOT23-5
8 1 TLC2932
TSSOP14
9 1 16.384MHZ
OSC003
10 1 MT48LC8M16A
2P-6A TSOP54
11 1 21375 M25P20
"U29"
ADSP-21375 EZ-KIT Lite Evaluation System Manual
"ADSP-21375 EZ-KIT Lite Sche-
Reference Manufacturer
Designator
U40 TI
U37 IDT
U1 DIGI-KEY
VR1 LINEAR TECH
U39 PHILIPS
VR2 LINEAR TECH
U16-18 TI
U38 TI
U28 EPSON
U7 MICRON
U29 ST MICRO
Part Number
74LVC14AD
IDT74FCT3244APYG
SG-8002CA-PCC-ND
(12.288M)
LT1765ES8#PBF
GTL2002DP-T
LTC1877EMS8#PBF
SN74LVC1G08DBVR
TLC2932IPWG4
SG-8002CA-MPT
MT48LC8M16A2P-6A
M25P20-VMN6TP
A-1
