Analog Devices EVAL-LTM4719-AZ User Manual

General Description
The EVAL-LTM4719-AZ evaluation board features the
®
LTM 4719, a 42V dual input, 150mA synchronous buck
power µModule ® (micromodule)
integrated battery health monitor and a low-dropout linear
regulator. The EVAL-LTM4719-AZ has a wide operating
input range of 2.4V to 42V and supports seamless
transition between the two separate input power sources.
The output has a range of 1V to 4.2V and can source up
to 150mA of continuous output current.
The EVAL-LTM4719-AZ also features an EXTV
(JP3) to V for improved efficiency in some
BUS
applications. The system can be monitored through
VALID1, VALID2, PRIORITY, and PG indicators. There
are accurate V and V
SET1
independent undervoltage lockout (UVLO) thresholds.
Fault protection features include input UVLO, power good,
current limit, and overtemperature protection. The built-in
precision coulomb counter supports input voltages from
1.8V to 5.5V and a peak current of up to 100mA. The
EVAL-LTM4719-AZ utilizes jumpers to easily program the
peak current limit of the coulomb counter from 5mA to
100mA by setting IPK0 (JP4), IPK1 (JP5), and IPK2 (JP6).
Evaluation Board Photo
Rev. 0
O n e A n a l o g W a y , W i l m i n g t o n , M A 0 1 8 8 7 - 2 3 5 6 , U . S . A .
42V Dual Input, Low Noise 150mA Step-Down µModule Regulator
regulator with
jumper
CC
comparators to program
SET2
Figure 1. EVAL-LTM4719-AZ Evaluation Board (Part Marking is Laser Mark)
Evaluation Board User Guide
EVAL-LTM4719-AZ
with I
The EVAL-LTM4719-AZ can be connected directly to a PC
at P1 using the DC1613A, Analog Devices I
PMBus dongle. The LTpowerPlay
a graphical user interface (GUI) and configure a battery
an
state of health (SoH) monitor.
Features and Benefits
•
Seamless Transition between Inputs
•
Compatible with LTpowerPlay
• Easy to use GUI for the Coulomb Counter
• Access Coulomb Counter Register Data
•
Optional Supercapacitor Balancer
EVAL-LTM4719-AZ Evaluation Board
FILE
EVAL-LTM4719-AZ
LTpowerPlay
DC1613A
Ordering Information
DOCUMENT FEEDBACK
T e l : 7 8 1 . 3 2 9 . 4 7 0 0 © 2 0 2 5 A n a l o g D e v i c e s , I n c . A l l r i g h t s r e s e r v e d .
C Battery Health Monitor
2
® allows the user to run
DESCRIPTION
Design files.
Easy-to-use Windows
GUI development tool.
The USB to PMBus
controller dongle.
appears at end of this user guide.
TECHNICAL SUPPORT
LTM4719
2
C/SMBus/
®
based
