Ruijie RG-AP680-I Hardware Installation And Reference Manual page 5

Hardware Installation and Reference Guide
GPS
Ports
Fat/Fit Mode
Switching
LED
Power Supply
PoE Output
Power Consumption
Temperature
Humidity
IP Rating
Weight
Safety Standards
EMC Standards
Table 1-2 LEDs of RG-AP680-I
LED
System status
WDS RSSI (3 LEDs in
total; available when
bridging is enabled)
Table 1-3 Reset Button of RG-AP680-I
Button
Reset button
Support
One 100/1000/2.5 G/5 G/10 G Base-T uplink Ethernet port
One SFP+ uplink port
One Console port
One multi-extend port (Extendable to two 10/100/1000 Base-T ports and one DC port)
Supported
One system status LED
Three WDS RSSI LEDs
Adapter: 40 V to 57 V DC (The RG-Cab-26APPD cable is required.)
PoE: IEEE 802.3af/at/3bt
Support IoT modules requiring input power of 12V/0.25A
DC/802.3bt: < 55W (Full load)
802.3at: < 25.5W (PoE output and third-radio bridging are disabled. The third radio fails to
work.)
802.3af: < 12.95W (The device can work with all radios disabled, broadcasting no signal.)
Operating: -40° C to 65° C (-40° F to 149° F)
Storage: -40° C to 85° C (-40° F to 185° F)
Operating: 0% to 100% (non-condensing)
Storage: 0% to 100% (non-condensing)
IP68
≤4.5kg (9.92 lbs)
GB 4943.1-2011, EN 60601-1-2 (medical care), UL/CSA 60950-1, EN/IEC 60950-1, EN/IEC
60950-22
GB/T 9254.1-2021, EN 301 489, EN55022, FCC Part15, RSS-210
State Meaning
Blinking green The system is booting.
Solid green Initialization in progress or proper operation.
Blinking orange Initialization is complete, but no CAPWAP connection.
Blinking red The uplink port is disconnected.
1 solid on < -70dBm
2 solid on -70 to -50dBm
3 solid on > -50dBm
State
When powered on,
pressed for less than 2s
When powered on,
pressed for more than 3s
Meaning
Resets the AP.
Restores the factory default settings.
Product Overview
·
·
