31a

Service parameters (10-199)

Circuit I
Lines Setting ranges
10 Choice of room panel / remote control
0 ...5
15 Adaptive function of room
temperature
OFF / 1 ... 30
21 Total stop
ON / OFF
25 Relay 1 (R1) function related to room
temperature
ON / OFF
30 Limitation temperature, sensor S4
10 ... 110 °C
35 Limitation temperature influence, max.
-9.9 ... 0 ... 9.9
36 Limitation temperature influence, min.
-9.9 ... 0 ... 9.9
37 Time constant for temperature
limitation
OFF / 1 ... 50
42 Time control of relay R2
1 / 2
57 Temperature influence by S4 , sliding
frost protection
0 ... 9.9
60 Compensation temperature, 1. point
-20 ... 110 °C
61 Compensation temperature influence,
1. point, max. limitation
-9.9 ... 0 ... 9.9
62 Compensation temperature influence,
1. point, min. limitation
-9.9 ... 0 ... 9.9
63 Time constant, compensation
temperature
OFF / 1 ... 50
64 Compensation temperature, 2. point
-20 ... 110 °C
65 Compensation temperature influence,
2. point, max. limitation
-9.9 ... 0 ... 9.9
66 Compensation temperature influence,
2. point, min. limitation
-9.9 ... 0 ... 9.9
81 Time constant of input for sensor S2
0 ... 99
82 Accumulation time constant for
temperature S2 (S3)
5 ... 250
85 Application type selection
0 ... 2
86 Relay R1 cut-in delay time
0 ... 899 sec.
87 Relay R2 cut-in delay time
0 ... 899 sec.
88 Output status, relay R1
0 ... 3
89 Output status, relay R2
0 ... 3
90 Definition of relay R3 function
0 ... 5
Factory settings
0
OFF
ON
OFF
25 °C
-4.0
0.0
OFF
1
4.0
25 °C
0.0
0.0
OFF
5 °C
0.0
0.0
70
50
0
180 sec.
0 sec.
1
1
0
Your settings
°C
°C
°C
sec.
sec.
