Danfoss ERC 113 Reference Manual

Bottle cooler controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

ERC 113 refrigeration controller
Bottle cooler controller
ERC 113
This reference manual is intended to be used primarily by OEMs for the purposes
of programming ERC 113. It may also be useful for technicians. It is not intended
as a user guide for end users.
www.danfoss.com/erc

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ERC 113 and is the answer not in the manual?

Questions and answers

Glen Choske
May 24, 2025

Installed a new erc 113 on my vegetable fridg.getting a red flashing light.no adjustments.plain box with indicator light

0

Subscribe to Our Youtube Channel

Related Manuals for Danfoss ERC 113

Summary of Contents for Danfoss ERC 113

  • Page 1 Bottle cooler controller ERC 113 This reference manual is intended to be used primarily by OEMs for the purposes of programming ERC 113. It may also be useful for technicians. It is not intended as a user guide for end users. www.danfoss.com/erc...
  • Page 2 The ERC 113 is built using the very best hardware technology and is the only controller on the market to offer a waterproof spindle.
  • Page 3 ERC 113 refrigeration controller Overview of the ERC 113 application setups: stand-alone, remote display and remote spindle. The ERC 113 stand-alone controller can be equipped with a variety of accessories, including remote display, remote spindle and multiple sensors. Overview of the system...
  • Page 4 2) ERC 113 + remote display The ERC 113 + remote display (RDI 107) is ideal for commercial freezers and fridges as well as glass door merchandisers. ERC remote displays allow for temperature...
  • Page 5 Relay 5 DI (not com) The table shows the possible input and output connections for the three application setups: ERC 113 stand-alone, ERC 113 + remote display and ERC 113 + remote spindle. Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07 DKRCC.ES.RL0.F5.02...
  • Page 6 3. Level 3: "OEM" (OEM programming). of temperature-sensitive food storage, breaches in food hygiene principles and regulations. Only a trained operator should make changes to parameters. DKRCC.ES.RL0.F5.02 Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07...
  • Page 7 ON (according to "FAo" and "Fod"). Default 0 s "FSt" Fan Minimum Stop time Minimum stop time for fan protection. Min. 0 s Max. 960 s Default 10 s Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07 DKRCC.ES.RL0.F5.02...
  • Page 8 Max. 55.0°C minimum temperature allowed in your application. Default 0.0°C For glass door merchandisers 0°C/32°F protects bottles from freezing; for commercial fridges you may opt for a slightly higher temperature (e.g. 2°C) DKRCC.ES.RL0.F5.02 Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07...
  • Page 9 Defrost settings "dFt" Defrost Type "no": defrost function is disabled. Default no "EL": electrical or time defrost. "Hgd": hot gas defrost (contact Danfoss for details). "nat": OFF-cycle defrost (natural defrost). "Add" Adaptive defrost "no": defrost controlled by time. Min. no "yES": automatic defrost control activated.
  • Page 10 "1-998": number of compressor cycles before deactivation. "999": initial defrost always active. Compressor settings "uPt" Voltage protection "no": no voltage protection. "yES": voltage protection activated based on voltage related settings. Min. no Max. yes Default no DKRCC.ES.RL0.F5.02 Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07...
  • Page 11 If set to zero, the function is disabled. Max. 15 min Default 0 min "Srt" System resume after door open Fan and Compressor resume after cut out by door open. Min. 0 min Max. 60 min Default 0 min Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07 DKRCC.ES.RL0.F5.02...
  • Page 12 The controller can have its display intensity (brightness) set in one of Min. 2 two ways: Max. 10 A) With a Danfoss ambient light sensor attached, the brightness of the Default 10 display is adjusted automatically according to the ambient light level (see the assignments section).
  • Page 13 "yES": show compressor symbol on display. Max. yes Default yes "SFS" Show Fan symbol "no": san symbol will not show on display. Min. no "yES": show fan symbol on display. Max. yes Default yes Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07 DKRCC.ES.RL0.F5.02...
  • Page 14 In some cases, it may be necessary for a user or technician to take action in order to clear the alarm. If set to 0, the alarm will never sound. DKRCC.ES.RL0.F5.02 Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07...
  • Page 15 ECO strategy NOTE: some of these parameters require the installation of the Danfoss Ambient Light Sensor. The Danfoss USB Gateway in combination with "Software tool" allows for real time measurement of the current light intensity. Danfoss recommends testing and adjusting "SLd" and "SLn"...
  • Page 16 ERC 113 refrigeration controller "ECt" Action counter time Door action or "PIR" action within action counter time can trigger Min. 0 min exiting ECO (can only be accessed by Danfoss). Max. 180 min Default 30 min "Edd" Door delay Door delay after door close to trigger entering ECO Min.
  • Page 17 NOTE: coded sensors will impact on the number of possible configurations. For instance: Danfoss supplies only 2-pole defrost sensors, so input "S3" will most likely be used as a defrost/evaporator temperature sensor input. Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07...
  • Page 18 "PiC": pilot Relay (no zero cross) – if using pilot relay to control a compressor, this option must be used instead of "CoP". "HEt": heating application, inverse output. "PiH": pilot heat relay (no zero cross). DKRCC.ES.RL0.F5.02 Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07...
  • Page 19 You may not therefore have access to change all the passwords. Passwords are entered by using the up and down arrow buttons. Min. 0 Max. 999 Danfoss advises against using passwords which are easy to remember Default 0 or enter, for example 111, 222, 123 etc. "PS3"...
  • Page 20 Serial number given at manufacturing. "Fir" SW version Danfoss software version number. "HAr" HW version Danfoss hardware version number. "onL" OrderNoLow Danfoss order code number. "onH" OrderNoHigh Danfoss order code number. "oEL" OEM code Low DKRCC.ES.RL0.F5.02 Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07...
  • Page 21 Device has not finished programming (relay output is lockt) "Eco" Device is in Eco mode "SC" Device is in pull-down mode (super-chill) "dEF" Device is defrosting "HoL" Device is in Holiday mode Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07 DKRCC.ES.RL0.F5.02...
  • Page 22 Blink "E03". If configured: cut in alarm relay, beep the buzzer "S3" sensor failure (short or open) "E04" "S4" error Always Blink "E04". If configured: cut in alarm relay, beep the buzzer "S4" sensor failure (short or open) DKRCC.ES.RL0.F5.02 Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07...
  • Page 23 "DO6" FLA2/LRA12, TV-1 8 A resistive, 2(2) A Max 10 A total "DO4-6" Danfoss NTC sensors and Danfoss ECO accessories (300 - 3,000 mm) Probes Danfoss PT1000 ohm/0°C Modular connector system for OEM customers, with optional output screw terminal adapter;...
  • Page 24 Ø5.90 Ø1.5 Remote display 28 mm 36,5 mm 47,25 mm 78,25 mm 51,25 mm 71 mm 71 mm 30 mm 28,5 mm Rear mounting Front mounting (Lock with clips) (Lock with frame) DKRCC.ES.RL0.F5.02 Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07...
  • Page 25 * Available optional plugs with screw connections are limited to 16 A S3, 1500 mm, 3-pole 077F8760 Note: For more information about temperature sensor types and connectors, please refer to Danfoss’ technical brochure "NTC type tempera- ture sensors for ETC & ERC controllers". Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07 DKRCC.ES.RL0.F5.02...
  • Page 26 3000 mm 080G3375 3000 mm 080G3342 3000 mm 080G3324 2000 mm 077F8765 3000 mm 077F8798 4000 mm 080G3343 2200 mm 077F8767 6000 mm 080G2029 3000 mm 077F8769 3500 mm 077F8723 6000 mm 080G2019 DKRCC.ES.RL0.F5.02 Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07...
  • Page 27 3500 mm 077F8723 RD107A, blue LED 080G3241 6000 mm 080G2019 RDI 107A AI/DI’s S1/S5 S2/S6 di connection Communication cable RD communication wire 3-pole 1000 mm 080G3381 2000 mm 080G3383 3000 mm 080G3385 Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07 DKRCC.ES.RL0.F5.02...
  • Page 28 The evaporator sensor is only used for de-icing of the evaporator and has no control purpose. Placement of sensor Place the sensor where the ice melts last. Please be aware of that sharp finns can damage the cable. DKRCC.ES.RL0.F5.02 Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07...
  • Page 29 The door sensor is used to detect buying activity and to stop the fan when the door is opened. Door sensor Danfoss does not supply the door-switch. Use the door-switch you have and connect it to the cable supplied by Danfoss.
  • Page 30 • have C2 connector condenser sensor or light sensor are optional and can be omitted • defrost sensor is mandatory when electrical heater is used for defrost. For natural defrost it can be omitted DKRCC.ES.RL0.F5.02 Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07...
  • Page 31 User manual ERC 113 refrigeration controller Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07 DKRCC.ES.RL0.F5.02...
  • Page 32 ERC 113 refrigeration controller Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alternations can be made without subsequential changes being necessary in specifications already agreed.

This manual is also suitable for:

Erc 113bErc 113aErc 113cErc 113d
