Introduction

Thank you for selecting a MOONS' motor control product. We hope our dedication to performance,
quality and economy will make your motion control successful.
If there's anything we can do to improve our products or help you use them better, please call or
fax. We'd like to hear from you. Our phone number is (021) 52634688, or you can reach us by fax
at (021) 62968682. You can also email to

Features

• Programmable, microstepping digital step motor driver in compact package
• MSSTAC5-2V models operate from 94-265VAC
• Ethernet 10/100 MBit communication
• Operates in velocity or position mode
• Accepts analog signals, digital signals, and Ethernet commands
• Accept incremental encoder feedback signal. Single-ended or Differential. (Optional)
• MSSTAC5-2V provides motor current up to 2.55 amps/phase (peak of sine)
• Communications:
Ethernet
• ±10 volt analog input for speed and position control. Can also be configured for 0 to 10V, ±5V
or 0 to 5V signal ranges.

List of MSSTAC5 Model Numbers

Model
MSSTAC5-S-N-2V
MSSTAC5-S-E-2V
MSSTAC5-Q-N-2V
MSSTAC5-Q-E-2V
An "E" in the model number indicates the inclusion of the models operate Encoder Feedback
connector.
An "N" in the model number indicates no encoder feedback connector on the drive.
info@moons.com.cn
Control Current
S
0.5-2.55A
Q
Voltage Encoder
√
94-265VAC
√
3
Expand
I/O
√
√
Rev. 1.0
05/07/2013
