STAC5 Ethernet Hardware Manual
INPUTS/OUTPUTS: Q
models only
NON-VOLATILE
STORAGE
AGENCY APPROVALS
HUMIDITY
AMBIENT
TEMPERATURE
DIMENSIONS
WEIGHT

Mating Connectors and Accessories

Mating Connectors
Power supply: Weidmuller P/N 1526510000
Motor: Weidmuller P/N 1526710000
IN/OUT1: DB-15 male. OUPIIN P/N 7907-15MTBC00A. Shell Kit OUPIIN P/N DP-15CP. Included.
IN/OUT2: DB-25 male. OUPIIN P/N 7907-25MTBC00A. Shell Kit OUPIIN P/N DP-25CP. Included.
Optional encoder feedback: DB-15 male. OUPIIN P/N 7917-15MTBC00A. Shell Kit OUPIIN P/N
DP-09CP. Included.
Rev. 1.0
05/07/2013
Q models have the same I/O as above plus the following:
IN1, IN2, IN7, IN8 inputs: Optically isolated, differential, 5-24 VDC logic
(2.5V switching threshold), 100 usec minimum pulse width, maximum
current = 10 mA.
IN3-IN6 inputs: Optically isolated, single-ended, shared common, sinking or
sourcing, 12-24 VDC logic, 2200 ohms, maximum current = 10 mA.
OUT1-OUT3 outputs: Optical darlington, single-ended, shared common,
sinking, 30 VDC max, 100 mA max, voltage drop = 1.2V max at 100 mA.
OUT4 output: Optical darlington, sinking or sourcing, 30 VDC max, 100 mA
max, voltage drop = 1.2V max at 100 mA.
Drive configuration and Q program are stored in FLASH memory onboard
the DSP.
"RoHS
CE EN61800-3:2004
UL 508c"
90% max, non-condensing
0 to 40 ºC (32 to 104 ºF) with adequate ventilation
122.5×128×49mm
22.4 oz (630 g)
