Moons' MSSTAC5 Hardware Manual page 22

STAC5 Ethernet Hardware Manual
Rev. 1.0
05/07/2013
5-24 VDC
Power Supply
+
IN/OUT2
OUT1/2/3
OUTCOM
Sourcing Output Using OUT1, OUT2 or OUT3
5-24 VDC
Power Supply
+
STAC5
OUT+
OUT-
Sourcing Output Using Y1, Y2 or OUT4
relay
OUT1/2/3
Drive
1N4935 suppression diode
OUTCOM
Driving a Relay Using OUT1,OUT2 or OUT3
relay
OUT+
Drive
1N4935 suppression diode
OUT-
Driving a Relay Using Y1, Y2, or OUT4
–
COM
PLC
IN
–
COM
PLC
IN
5-24 VDC
Power Supply
+ –
5-24 VDC
Power Supply
+ –
