DEMO MANUAL DC2702A-A
PARTS LIST
ITEM QTY REFERENCE
25 15 R10, R11, R12, R13, R14, R15, R16,
R18, R19, R24, R52, R77, R94, R95,
R106
26 1 R30
27 1 R31
28 1 R48
29 2 R50, R51
30 1 R53
31 2 R72, R73
32 1 R78
33 1 R90
34 1 U1
35 1 U2
36 3 XJP1, XJP2
37 1
38 0
39 1
40 0
41 0
42 1
43 0
44 0
45 0
46 0
47 0
10
PART DESCRIPTION
RES., 10kΩ, 5%, 1/10W, 0603, AEC-Q200
RES., 2.43kΩ, 1%, 1/10W, 0603, AEC-Q200
RES., 4.22kΩ, 1%, 1/10W, 0603, AEC-Q200
RES., 0Ω, 3/4W, 2010, AEC-Q200
RES., 30Ω, 1%, 1W, 2512, AEC-Q200
RES., 0.01Ω, 1%, 1/2W, 2010, SENSE, AEC-Q200
RES., 4.99kΩ, 1%, 1/10W, 0603, AEC-Q200
RES., 15.8kΩ, 1%, 1/10W, 0603, AEC-Q200
RES 0.001Ω, 1%, 1W, 2010
IC, DUAL 50A POP PSM MODULE,
BGA 15 × 22 × 7.82mm
IC, MEMORY, EEPROM, 2Kb (256x8), TSSOP-8,
400kHz
CONN., SHUNT, FEMALE, 2 POS, 2mm
LABEL SPEC, DEMO BOARD SERIAL NUMBER
PCA ASSY DWG, DC2702A
TOOL, STENCIL, 700-DC2702A
RES., OPTION, 1206
CAP ., OPTION, 0603
PCB, DC2702A
RES., OPTION, 0805
CAP ., OPTION, D-CASE
RES., OPTION, 0603
RES., OPTION, 2010
DIODE, OPTION, SOD-323
MANUFACTURER/PART NUMBER
PANASONIC, ERJ3GEYJ103V
VISHAY, CRCW060310K0JNEA
NIC, NRC06F2431TRF
PANASONIC, ERJ3EKF2431V
VISHAY, CRCW06032K43FKEA
NIC, NRC06F4221TRF
PANASONIC, ERJ3EKF4221V
VISHAY, CRCW06034K22FKEA
NIC, NRC50ZOTRF
PANASONIC, ERJ12ZY0R00U
VISHAY, CRCW20100000Z0EF
VISHAY, CRCW251230R0FKEG
VISHAY, WSL2010R0100FEA
NIC, NRC06F4991TRF
PANASONIC, ERJ3EKF4991V
VISHAY, CRCW06034K99FKEA
NIC, NRC06F1582TRF
PANASONIC, ERJ3EKF1582V
VISHAY, CRCW060315K8FKEA
VISHAY, WSL20101L000FEA18
ANALOG DEVICES, LTM4700EY#PBF
MICROCHIP , 24LC025-I/ST
MICROCHIP , 24LC025T-I/ST
WURTH ELEKTRONIK, 60800213421
BRADY, THT-96-717-10
ANALOG DEVICES, 830-DC2702A
PHASE 3 TECHNOLOGIES INC.,
600-DC2702A
Rev 0
