FC 300 Instruction Manual
Data storage in LCP:
Go to par. 0-50 LCP copy
1.
Press the [OK] key
2.
3. Select "All to LCP"
Press the [OK] key
4.
All parameter settings are now stored in the LCP indicated by the progress bar.
When 100% is reached, press [OK].
NOTE
Stop the unit before performing this operation.
You can now connect the LCP to another adjustable frequency drive and copy the parameter
settings to this adjustable frequency drive as well.
Data transfer from LCP to drive:
1. Go to par. 0-50 LCP copy
2. Press the [OK] key
Select "All from LCP"
3.
Press the [OK] key
4.
The parameter settings stored in the LCP are now transferred to the drive indicated by
the progress bar. When 100% is reached, press [OK].
NOTE
Stop the unit before performing this operation.

Reset to Default Setting

"
To restore all parameter values to their default setting, go to par. 14-22 Operating Mode and
select Initialization. Power down the adjustable frequency drive. The adjustable frequency drive
will automatically restore to default settings during the next power-up.

Adjust Display Contrast

"
Hold down [STATUS] and use the up or down navigation arrow to adjust the display contrast
How to Program
MG.33.A4.22 - VLT is a registered Danfoss trademark
39
