Table 2.

Number
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
-
Pin description (continued)
Type Name
O OUT1B
PWR VCC1
PWR GND1
O OUT1A
PWR GND_REG
PWR VDD_REG
I CONFIG
- N.C.
- N.C.
- N.C.
- N.C.
PWR VDD_DIG
PWR GND_DIG
I PWRDN
PWR VDD_PLL
I FILTER_PLL
PWR GND_PLL
I XTI
I BICKI
I LRCKI
I SDI
I RESET
O INT_LINE
I/O SDA
I SCL
PWR GND_DIG
PWR VDD_DIG
- EP
Doc ID 13365 Rev 2
Description
Output half bridge 1B
Power positive supply
Power negative supply
Output half bridge 1A
Internal ground reference
Internal 3.3-V reference voltage
Paralleled mode command
No internal connection
No internal connection
No internal connection
No internal connection
Positive supply digital
Digital ground
Power down:
0: power stage is switched off then the PLL is also
switched off (this operation take 13 million clock cycles)
1: normal operation
Positive supply for PLL
Connection to PLL filter
Negative supply for PLL
PLL input clock, 256 * f
S
2
I S serial clock
2
I S left/right clock
2
I S serial data channel
Reset:
0: reset state, power stage is switched off, all registers are
set to default value
1: normal operation
Fault interrupt
2
I C serial data, used as SDA_OUT
2
I C serial clock
Digital ground
Digital supply
Exposed pad for ground-plane heatsink, to be connected
to GND
Pin description
, or 384 * f
S
