Electrical specification

3.1

Absolute maximum ratings

Table 4.
Symbol
V
CC
V
DD
I
L
T
op
T
stg
Warning:
3.2

Recommended operating conditions

Table 5.
Symbol
V
CC
V
DD
I
L
T
amb
Absolute maximum ratings
Analog supply voltage (pins VCCx)
Digital supply voltage (pins VDD_DIG)
Logic input interface
Operating junction temperature
Storage temperature
Stresses beyond those listed in
ratings may cause permanent damage to the device. These
are stress ratings only, and functional operation of the device
at these or any other conditions beyond those indicated in
Table 5: Recommended operating conditions
Exposure to absolute-maximum-rated conditions for
extended periods may affect device reliability. In the real
application, a power supply with nominal value rated within
the limits of the recommended operating conditions, may
experience some rising beyond the maximum operating
conditions for a short time when no or very low current is
being sinked (amplifier in mute state). In this case the
reliability of the device is guaranteed, provided that the
absolute maximum ratings are not exceeded.
Recommended operating conditions
Analog supply voltage (VCCx)
Digital supply voltage (VDD_DIG)
Logic input interface
Ambient temperature
Doc ID 13365 Rev 2
Parameter
Table 4: Absolute maximum
Parameter
Electrical specification
Min Typ Max Unit
- - 23 V
- - 4.0 V
-0.3 - 4.0 V
0 - 150 °C
-40 - 150 °C
are not implied.
Min Typ Max Unit
4.5 - 20.0 V
2.7 3.3 3.6 V
2.7 3.3 3.6 V
0 - 70 °C
