Volume Control Registers (Addr 0X06 To 0X09); Mute/Line Output Configuration Register (Addr 0X06); Table 39. Master Mute; Table 40. Channel Mute - ST Sound Terminal STA333W Manual

Register description
6.2

Volume control registers (addr 0x06 to 0x09)

6.2.1

Mute/line output configuration register (addr 0x06)

D7
0
Master mute
Table 39.
Bit
0
Channel mute
Table 40.
Bit
1
2
32/49
D6 D5
Reserved
0 0
Master mute
R/W RST
R/W 0 MMUTE
Channel mute
R/W RST Name
R/W 0 C1M
R/W 0 C2M
Doc ID 13365 Rev 2
D4 D3
0 0
Name
0: normal operation
1: all channels are in mute condition
Channel 1 mute:
0: not muted, it is possible to set the channel volume
1: hardware muted
Channel 2 mute:
0: not muted, it is possible to set the channel volume
1: hardware muted
STA333W
D2 D1
C2M C1M
0 0
Description
Description
D0
MMUTE
0
