2-channel high-efficiency digital audio system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Features
Wide supply-voltage range (4.5 V - 20 V)
2 power output configurations
– 2 channels of binary PWM (stereo mode)
– 2 channels of ternary PWM (stereo mode)
PowerSSO-36 with exposed pad down
2 channels of 24-bit DDX
100-dB SNR and dynamic range
Selectable 32- to 192-kHz input sample rates
2
I
C control with selectable device address
Digital gain -80 dB to +48 dB in 0.5-dB steps
Software volume update
Individual channel and master gain/attenuation
Individual channel and master software and
hardware mute
Independent channel volume bypass
Automatic zero-detect mute
Automatic invalid input detect mute
2
2-channel I
S input data Interface
Selectable clock input ratio
Input channel mapping
Automatic volume control for limiting maximum
power
96-kHz internal processing sample rate, 24-bit
precision
Advanced AM interference frequency
switching and noise suppression modes
Thermal-overload and short-circuit protection
embedded
Video application: 576 * f
Table 1.
Device summary
Order code
STA333W
STA333W13TR
January 2010
2-channel high-efficiency digital audio system
®
input mode support
S
Package
PowerSSO-36 EPD
PowerSSO-36 EPD
Doc ID 13365 Rev 2
Applications
LCD
DVD
Cradle
Digital speaker
Wireless-speaker cradle
Description
The STA333W is an integrated circuit comprising
digital audio processing, digital amplifier control
®
and DDX
power output stage to create a high-
power, single-chip DDX
amplification with high quality and high efficiency.
The STA333W power section consists of four
independent half-bridges stages. These can be
configured via digital control to operate in different
modes. 2 channels can be provided by two full
bridges, providing up to 20 W + 20 W of power.
Also provided in the STA333W are new advanced
AM radio interference reduction modes. The serial
audio data input interface accepts all possible
formats, including the popular I
®
channels of DDX
processing are provided.
The STA333W is part of the Sound Terminal™
family that provides full digital audio streaming to
the speaker offering cost effectiveness, low power
dissipation and sound enrichment.
Tube
Tape and reel
STA333W
Sound Terminal™
PowerSSO-36 package
with exposed
pad down (EPD)
®
solution for all-digital
2
S format. Three
Packaging
www.st.com
1/49
49
