8. Specification

8.1. Specifications

Item
General
Protection class
Standards
Dimensions (W x L x H)
Housing material
Weight
Maximum number of ejectors
Maximum number of sensors
Withstand voltage
Insulation resistance
Operating temperature range
Storage temperature range
Operating humidity range
Electrical
Operating voltage
For logic/input Current consumption
Under-voltage detection approx. 18 VDC
For output Operating voltage
Protection against polarity reversal
Loop through current between power
connectors
Galvanic isolation
Fieldbus
Bus protocol
Version
Communication speed
FoE
CoE
Configuration file
Vendor ID
Product Code
Table 8-1. Specifications
IP67 (when connected with the vacuum manifold, it is IP65)
CE/UKCA Marking
25.5 x 98.7 x 76.5
PBT
150 g
16
16
500 VAC 1 min. (between FE and all accessible terminal)
10 M ohm or more (500 VDC between FE and all accessible terminal)
0 °C...50 °C
-20 °C...60 °C
35 %...85 %RH (non-condensing)
24 VDC +10%/-10%
100 mA or less (at 24 VDC)
24 VDC +10%/-5%
Yes (PWR and PWR(V))
4 A
Yes (between PWR and PWR(V))
EtherCAT
®
Conformance Test Record V2.3.0
100 Mbps
Supported
Supported for parameter setting and diagnostics etc.
XML file
0x00000114
0x0100004F
