Attaching cables

Connect the printer to the computer using a USB or parallel cable, or to the network using an Ethernet
cable.
Make sure to match the following:
• The USB symbol on the cable with the USB symbol on the printer
• The appropriate parallel cable with the parallel port
• The appropriate Ethernet cable with the Ethernet port
Warning—Potential Damage: Do not touch the USB cable, any network adapter, or the printer in the
area shown while actively printing. Loss of data or a malfunction can occur.
Use the
1
USB port
2 USB printer port
3 Ethernet port
4
Parallel port
5 Power switch
6 Printer power cord socket
7
Security slot
User's Guide
To
Attach an optional wireless network adapter.
Connect the printer to a computer.
Connect the printer to a network.
Connect the printer to a computer.
Turn on or turn off the printer.
Connect the printer to an electrical outlet.
Attach a lock that will secure the printer in place.
- 23 -
