Chapter 2: Jumpers and Connectors

SATA Power Connector

Connector type: 1x4 4-pin Wafer, 2.54mm pitch
Connector location: CN3
1 4
Pin Definition
1 P12V
3 GND
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 GND
4 TXP

SATA Connector

Connector type: Standard Serial ATA 7P (1.27mm, SATA-M-180)
Connector location: CN4
1 7
Pin Definition
1 GND1
3 TXN
5 RXN
7 GND3
16
Pin Definition
2 TXP
4 GND2
6 RXP
