Nexcom DNA 130 User Manual page 47

Chapter 4: BIOS Setup
Pending operation
Schedules an operation for the security device.
Platform Hierarchy
Enables or disables platform hierarchy.
Storage Hierarchy
Enables or disables storage hierarchy.
Endorsement Hierarchy
Enables or disables endorsement hierarchy.
TPM2.0 UEFI Spec Version
Configures the TPM2.0 UEFI spec version.
Physical Presence Spec Version
Configures the physical presence spec version.
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
NCT6776 Super IO Configuration
This section is used to configure the serial ports.
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Advanced
NCT6776 Super IO Configuration
Super IO Chip
Serial Port 1 Configuration

Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
Super IO Chip
Displays the Super I/O chip used on the board.
Serial Port 1 Configuration
Configuration settings for serial port 1.
33
Set Parameters of Serial Port
1 (COMA)
NCT6776
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
DNA 130 User Manual
