380/381 Synergy Indicator
12.0

Specifications

380-2D (PN 202711)
Power
Four Alkaline C-Cell Batteries
Optional 115/230 VAC to 12 V adapter
Power Consumption
8.5 W max with optional external power adapter
Battery Life
100 hours on Alkaline batteries with one 350Ω load cell, no backlight
45 hours on Alkaline batteries with four 350Ω load cells, low backlight
20 hours on Alkaline batteries with eight 350Ω load cells, low backlight
Excitation Voltage
5 VDC, 8 x 350Ω or 16 x 700Ω load cells
Analog Signal Input Range
-0.3 mV to +30 mV
Common Mode Voltage 0.7 V to 3.3 V
Analog Signal Sensitivity
1 µV/graduation recommended
A/D Sample Rate
Software Selectable (Hz)
5, 6, 10, 12, 20, 25, 40, 50, 80, 100
Resolution
Internal: 8,000,000 counts
Display: 100,000
System Linearity
Within 0.01% full scale
Communication Ports
One RS-232 (three-wire)
One USB 2.0
Status Annunciators
g, lb, t, tn, kg, oz, battery level, PT, LT, gross, zero, unstable, net
Display
Six 1.0 in (25 mm) tall, LCD digits
Keys / Buttons
Five tactile buttons
Dimensions (L x W x H)
11.58 x 74.53 x 8.57 in (294 x 115 x 218 mm)
62 Visit our website
www.RiceLake.com
Temperature Range
Legal: 14–104°F (-10–40°C)
Industrial: 14–122°F (-10–50°C)
Rating/Material
Rating: IP66
Material: Stainless Steel
Warranty
Two-year limited warranty
EMC Immunity
10 V/m
Certifications and Approvals
380 Universal
NTEP
CoC Number: 21-051A1
Accuracy Class: III / IIIL; n
Measurement Canada
Approval Number: AM-6184
Accuracy Class: III / IIIHD; n
UL
File Number: E151461
: 10 000
max
: 10 000
max
