380/381 Synergy Indicator
Command
SC.MAX_DATE#n Date of maximum weighment (read only)
SC.WMTTHRH#n Weighment threshold
SC.DIGFLTR1#n Number of A/D samples averaged for the individual
SC.DIGFLTR2#n stages (1-3) of the three stage digital filter
SC.DIGFLTR3#n
SC.DFSENS#n Digital filter cutout sensitivity
SC.DFTHRH#n Digital filter cutout threshold
SC.SMPRAT#n Scale A/D sample rate
SC.PWRUPMD#n Power up mode
SC.TAREFN#n Tare function
SC.PRI.FMT#n Primary units format (decimal point and
display divisions)
SC.PRI.UNITS#n Primary units
SC.SEC.FMT#n Secondary units format (decimal point and
display divisions)
SC.SEC.UNITS#n Secondary units
SC.SEC.ENABLED#n Enable the Secondary Units
SC.FILTERCHAIN#n Defines what filter to use
SC.RTZGRAD#n Number of graduations from the zero base at which the
accumulator re-arms itself
SC.ACCUM#n Accumulator enable
SC.WZERO#n Perform zero calibration
SC.TEMPZERO#n Perform temporary zero calibration
SC.LASTZERO#n Perform last zero calibration
SC.WVAL#n Test weight value
SC.WSPAN#n Perform span calibration
SC.WLIN.F1#n– Actual raw count value for linearization points 1–4
SC.WLIN.F4#n
SC.WLIN.V1#n– Test weight value for linearization points 1–4 (A setting
SC.WLIN.V4#n of 0 indicates the linearization point is not used)
SC.WLIN.C1#n– Perform linearization calibration on points 1–4
SC.WLIN.C4#n
SC.LC.CD#n Zero (deadload) coefficient raw count value
SC.LC.CW#n Span coefficient raw count value
SC.LC.CZ#n Temporary zero raw count value
SC.REZERO#n Perform the Rezero calibration function
For commands ending with #n, n is the scale number (1)
7.5

USB Setting Commands

Command
USB.TRIGGER USB serial function
USB.LINETERM USB line termination characters
USB.ECHO USB echo
USB.RESPONSE USB response
USB.EOLDLY USB end-of-line delay
46 Visit our website
Description
Table 7-4. Scales Commands (Continued)
Description
CMD (default), STRIND, STRLFT
CR/LF (default), CR
ON, OFF (default)
ON (default), OFF
0–255 (0.1-second intervals), 0 (default)
Table 7-5. USB Port Commands
www.RiceLake.com
Values
Up to 25 alphanumeric characters (Only available if RTC option
is installed)
0.0–999999.0, 1000.0 (default)
1, 2, 4 (default), 8, 16, 32, 64, 128, 256
2OUT (default), 4OUT, 8OUT, 16OUT, 32OUT, 64OUT, 128OUT
NONE (default), 2D, 5D, 10D, 20D, 50D, 100D, 200D, 250D
5HZ, 6HZ, 10HZ, 12HZ, 20HZ, 25HZ (default), 40HZ, 50HZ,
80HZ, 100HZ
GO (default), DELAY
BOTH (default), KEYED, NOTARE, PBTARE
888100, 888200, 888500, 888810, 888820, 888850,
888881 (default), 888882, 888885, 88888.1, 88888.2, 88888.5,
8888.81, 8888.82, 8888.85, 888.881, 888.882, 888.885,
88.8881, 88.8882, 88.8885, 8.88881, 8.88882, 8.88885
LB (default), KG, OZ, TN, T, G, NONE
888100, 888200, 888500, 888810, 888820, 888850, 888881,
888882, 888885, 88888.1, 88888.2, 88888.5 (default), 8888.81,
8888.82, 8888.85, 888.881, 888.882, 888.885, 88.8881,
88.8882, 88.8885, 8.88881, 8.88882, 8.88885
LB, KG (default), OZ, TN, T, G, NONE
ON (default), OFF
AVGONLY (default), RAW
0.0–100.0, 0.4 (default)
OFF (default), ON
—
—
—
0.000001–999999.999999, 10000.0 (default)
—
0–16777215, 0 (default)
0.000001–999999.999999, 0.0 (default)
—
0–16777215, 8386509 (default)
0–16777215, 2186044 (default)
0–16777215, 2186044 (default)
—
Values
