10.3 Continuous Data (Stream) Output Formats

When the trigger setting for a port is set to STRIND or STRLFT, data is continuously streamed from the appropriate port in one
of the four fixed format options.
Fixed Format Options:
• Rice Lake Weighing Systems
• Cardinal (Section 10.3.2)
• Avery Weigh-Tronix (Section 10.3.3 on page
• Mettler Toledo (Section 10.3.4 on page

10.3.1 Rice Lake Weighing Systems Stream Format (RLWS)

<STX>
ASCII 002
Polarity:
<space> = Positive
<–> = Negative
Weight: 7 digits, right-justified, dummy
zeroes, decimal point with no leading
zeroes except for leading zero immediately
preceding the decimal point. Leading
zeroes transmitted as spaces.

10.3.2 Cardinal Stream Format (crdnal)

<CR> <POL> <wwwwww> <S> <SP> <UNIT> <SP> <G/N> <SP> <SP> <ETX>
Carriage
Return
Polarity:
<+> for positive
"–" for negative
Six digits, right justified, floating decimal
(follows weight if not embeded),
leading zeroes are present.
54 Visit our website
(Section 10.3.1)
55)
55)
<POL> <wwwwwww>
Figure 10-1. Rice Lake Weighing Systems Stream Data Format
Space
Character
Status:
<space> = valid or invalid
m = motion
o = over/under range
Figure 10-2. Cardinal Stream Data Format
www.RiceLake.com
<UNIT> <G/N>
G = Gross
N = Net
L = pounds
K = kilograms
T = tons
G = grams
O = ounces
Space g for Gross
Character n for Net
Space character
lb = pound
kg = kilogram
g = gram
tn = ton (short)
t = ton (metric)
oz = ounce
<space> = none
<S> <TERM>
<CR> <LF>
or <CR>
Status:
<space> = valid
I = Invalid
M = Motion
O = Over/under range
Z = COZ
Hex value of <03>
is entered in string
(2)
