380/381 Synergy Indicator

10.6 ASCII Character Chart

Use the decimal values for ASCII characters listed in
menu (Section 4.3.6 on page
The 380/381 can send or receive ASCII character values (decimal 0–255), but the indicator display is limited to numbers,
uppercase, unaccented letters and a few special characters. See
LCD display.
Control ASCII Dec
Ctrl-@ NUL 00
Ctrl-A SOH 01
Ctrl-B STX 02
Ctrl-C ETX 03
Ctrl-D EOT 04
Ctrl-E ENQ 05
Ctrl-F ACK 06
Ctrl-G BEL 07
Ctrl-H BS 08
Ctrl-I HT 09
Ctrl-J LF 10
Ctrl-K VT 11
Ctrl-L FF 12
Ctrl-M CR 13
Ctrl-N SO 14
Ctrl-O SI 15
Ctrl-P DLE 16
Ctrl-Q DC1 17
Ctrl-R DC2 18
Ctrl-S DC3 19
Ctrl-T DC4 20
Ctrl-U NAK 21
Ctrl-V SYN 22
Ctrl-W ETB 23
Ctrl-X CAN 24
Ctrl-Y EM 25
Ctrl-Z SUB 26
Ctrl-[ ESC 27
Ctrl-\ FS 28
Ctrl-] GS 29
Ctrl-^ RS 30
Ctrl-_ US 31
58 Visit our website
Table 10-4
37). The actual character printed depends on the character mapping used by the output device.
Hex ASCII Dec
00 space 32
01 ! 33
02 " 34
03 # 35
04 $ 36
05 % 37
06 & 38
07 ' 39
08 ( 40
09 ) 41
0A * 42
0B + 43
0C , 44
0D - 45
0E . 46
0F / 47
10 0 48
11 1 49
12 2 50
13 3 51
14 4 52
15 5 53
16 6 54
17 7 55
18 8 56
19 9 57
1A : 58
1B ; 59
1C < 60
1D = 61
1E > 62
1F ? 63
Table 10-4. ASCII Character Chart
www.RiceLake.com
when specifying print format strings on the 380/381 PFORMT
Section 10.7 on page 59
Hex ASCII Dec
20 @ 64 40
21 A 65 41
22 B 66 42
23 C 67 43
24 D 68 44
25 E 69 45
26 F 70 46
27 G 71 47
28 H 72 48
29 I 73 49
2A J 74 4A
2B K 75 4B
2C L 76 4C
2D M 77 4D
2E N 78 4E
2F O 79 4F
30 P 80 50
31 Q 81 51
32 R 82 52
33 S 83 53
34 T 84 54
35 U 85 55
36 V 86 56
37 W 87 57
38 X 88 58
39 Y 89 59
3A Z 90 5A
3B [ 91 5B
3C \ 92 5C
3D ] 93 5D
3E ^ 94 5E
3F _ 95 5F
for information about the 380/381
Hex ASCII Dec
` 96 60
a 97 61
b 98 62
c 99 63
d 100 64
e 101 65
f 102 66
g 103 67
h 104 68
i 105 69
j 106 6A
k 107 6B
l 108 6C
m 109 6D
n 110 6E
o 111 6F
p 112 70
q 113 71
r 114 72
s 115 73
t 116 74
u 117 75
v 118 76
w 119 77
x 120 78
y 121 79
z 122 7A
{ 123 7B
| 124 7C
} 125 7D
~ 126 7E
DEL 127 7F
Hex
