10.0

Appendix

10.1 Error Messages

The 380/381 provides a number of front panel error messages to assist in problem diagnosis.
and their meanings.
Error Message
-------
vvvvvvv
tare in motion not allowed
negative tare not allowed
keyed tare not allowed
tare larger than capacity
not allowed
tare already in system
initial zero failed
please wait

10.2 ZZ EDP Command

The ZZEDP command can be used to remotely query whatever is being displayed on the LCD Display, along with a decimal
number representing the annunciators currently lit. The format on the returned value is WWWWWW UU NNN in weight display
modes, and VVVVVV NNN in non-weight display modes. NNN is a number between 0 and 4095, and is the sum of values
representing the different annunciators
Example: If the annunciator status value returned for the ZZ command is 0145, the gross, standstill and lb annunciators are on.
The number 0145 represents the sum of the values for the gross mode annunciator (16), the standstill annunciator
(128) and the lb annunciator (1).
NOTE: Standstill bit is set when the In-Motion annunciator is NOT lit.
Overflow error – Weight value too large to be displayed
Gross > overload limit – Gross value exceeds overload limit; Check configuration or signal input level; Overload can
be caused by input signal > 45 mV or common mode voltage > 950 mV
Gross < underload limit – Gross value exceeds underload limit
Scrolls across display when attempting to perform a tare while weight is in motion, if in motion tares are not allowed
Scrolls across display when attempting to perform a negative tare, if a negative tare is not allowed
Scrolls across display when attempting to perform a keyed tare, if a keyed tare is not allowed
Scrolls across display when attempting to perform a tare larger than capacity, if it is not allowed
Scrolls across display when attempting to perform a tare if a tare is already in the system, if tare is not configured to
replace or remove
Scrolls across display when an attempt to perform an initial zero fails, only possible at startup
Scrolls across display when calibrating
Table 10-1. Error Messages
(Table 10-2).
Decimal Value
1 lb units
2 kg units
4 Tare entered
8 Keyed tare entered
16 Gross
32 Net
64 Center of zero
128 Standstill
256 oz units
512 tn units
1024 t units
2048 g units
Table 10-2. Status Codes Returned on the ZZ Command
© Rice Lake Weighing Systems ● All Rights Reserved
Description
Annunciator
Appendix
Table 10-1 lists these messages
