Polyend Tracker Mini Manual page 92

8
Audio
Global Mixer - Page 3
The Global Mixer is the third page in the master pages and contains the line
in level and line in delay / reverb send levels for the pass through. Also the
overall master delay, reverb level and dry / wet mix are available. These
can all be muted and all soloed, with the exception of the line delay and
reverb which can only be muted / unmuted. Press button [4] to cycle pages.
Global Mixer
Page 3 of 3
Actual stereo level.
Centre + Right bars
Global Mixer 3/3 0m:00s P1.008
Delay Reverb Dry Mix Line In Line Dly
-4.50 dB 0.00 dB 1.80 dB 0.00 dB 0.00 dB
Mute Mute Mute Unmute Unmute
Level
Left bar is the level setting
also displayed in the label
area. Also controllable by
MIDI CC79-82 Line Input Passthrough
Line In level, Delay and
Reverb Send amounts.
Function Command
Adjust Level Hold Option Screen Button 1-6 + Press (Up) or (Down) or [+] / [-]
Mute Option Press Option Screen Button 1-6 to toggle Mute / Unmute
Unmute Track Press Option Screen Button 1-6 to toggle Mute / Unmute
Solo Option Hold [Shift] + Press Option Screen Button 1-4 to toggle Solo on/off
Mute Button Behaviour.
In the master section mute is applied when the button is released after being pressed. This is different to muting
in the Pattern section where mutes are applied immediately when the button is pressed.
182
Line Rvb
Delay
Displays and adjusts amount of
master (all tracks) delay amount.
Reverb
Displays and adjusts amount of
master (all tracks) reverb amount.
Dry / Wet
Displays and adjusts mix level of
the delay and reverb and the
unaffected dry signal.
0.00 dB
Unmute
Polyend Tracker Mini Manual
NOTES NOTES
Polyend Tracker Mini Manual
8.2 Audio Sources
There are a number of sources where Tracker Mini can access audio.
Some of which are 'live' sources and can easily be sampled. Others are
manually managed or rendered within the device.
SD Card Samples
4
Folder
Audio samples
Microphone
2
Internal Microphone.
Line Input
1
External audio gear connection.
Line Input
1
3.5mm Input jack which allows Stereo (TRS) and Mono (TS) audio inputs. Stereo
signals are converted to mono when recorded and the L & R channels can also
be selected individually.
Microphone
2
The Tracker Mini has an internal microphone located on the front panel. This
allows direct recording of vocals, environmental sounds and general audio.
Render
3
A feature which is available with the internal functions is render. This bounces or
exports an audio file based on the selected pattern / tracks which can then be
made immediately available as a sample or to use from the instrument list.
SD Card
4
Audio samples are stored on the SD Card. These can be sampled and stored
from within Tracker Mini but also can be manually transferred onto the SD card
from and external source using a PC or Mac.
Tracker Mini is supplied with a 3.5mm Stereo Male Jack to 2 x 6.3mm Mono Female Socket
adapter to allow interfacing with external gear and using the more common 6.3mm mono cables.
8
Audio
Render
3
Bounce Internal Audio.
