Polyend Tracker Mini Manual page 132

11
MIDI
▌ SETTING UP A MIDI SYNTHESIZER
1. Ensure the external device is configured to set MIDI CC as per the
Tracker Mini CC assignments in the MIDI Synthesizer page. Also that
the MIDI configuration is matched, for example same MIDI channel.
2. Connect the external controller to Tracker Mini, for example using the
MIDI In connection and a MIDI cable between devices. Tracker Mini
uses a MIDI dongle to convert between MIDI 5 Pin DIN and Mini Jack.
3. To get the reference of CC configurations set up as default for Tracker
Mini, Press [2] for the Instrument Parameter page 1 or use the [Menu].
4. Press [More] which is the 8 th Screen button to display the Instrument
effects page.
5. Press [Instrument Synthesizer] Screen Button.
6. The CC's are displayed in the left window as a reference. There is no
selection in this page window as this is shown only as a guide.
7. To select an instrument as the destination target from the MIDI
controller and as the synthesizer instrument, scroll the right window to
select the desired instrument. This is also displayed in the top row.
8. The lists can be scrolled with the screen buttons. If the window is
selected, highlighted red, the (Up) and (Down) or the [+] / [-] buttons.
9. The instrument parameters will adjust when controlled by the external
MIDI controller. The changes are animated real time on the instrument
parameter displays.
262
NOTES
Polyend Tracker Mini Manual
NOTES
Synthesizer Mode - MIDI CC Configurations
CC # Function
5 Tune
3 Finetune
7 Volume
9 Filter Type
1 Cutoff
11 Resonance
12 Overdrive
13 Bit Depth
14 Reverb Send
15 Delay Send
20 Volume Automation Type
21 Volume - Attack - Shape LFO
22 Volume - Decay - Speed LFO
23 Volume Sustain
24 Volume Release
25 Volume Amount
26 Panning Automation Type
27 Panning - Attack - Shape LFO
28 Panning - Decay - Speed LFO
29 Panning Sustain
30 Panning Release
31 Panning Amount
Polyend Tracker Mini Manual
11
MIDI
CC # Function
83 Cutoff Automation Type
84 Cutoff - Attack - Shape LFO
85 Cutoff - Decay - Speed LFO
86 Cutoff Sustain
87 Cutoff Release
88 Cutoff Amount
102 Wavetable Position Automation Type
103 Wavetable Position - Attack - Shape LFO
104 Wavetable Position - Decay - Speed LFO
105 Wavetable Position Sustain
106 Wavetable Position Release
107 Wavetable Position Amount
108 Granular Position Automation Type
109 Granular Position - Attack - Shape LFO
110 Granular Position - Decay - Speed LFO
111 Granular Position Sustain
112 Granular Position Release
113 Granular Position Amount
114 Finetune Automation Type
115 Finetune - Attack - Shape LFO
116 Finetune - Decay - Speed LFO
117 Finetune Sustain
118 Finetune Release
263
