MIDI
11.9 MIDI Synthesizer
The MIDI synthesizer mode is a feature that allows integration when
controlling Tracker Mini from an external MIDI device and by controlling up
to 8 voices across MIDI. Tracker Mini will operate as a secondary follower
to an external controller which will be able to play and control Tracker Mini's
instruments. This also brings a tight integration between Tracker, Tracker
Mini and Polyend Play, where the MIDI CC is pre-mapped.
MIDI IN
Note Instr FX1 FX 2
+
Play Rec
+
Insert Menu
-
Delete Copy -
1 2 3 4
Shift
Line In Line Out MIDI In MIDI Out
Tracker Mini: Play:
[Menu] > Config > MIDI Menu > MIDI > CC Mapping > Jack Channel 1
Clock In MIDI In jack
Choose: Set Values for Polyend Tracker Mini
Clock out Off
Transport in MIDI In jack The rotary controls in play will be automatically
mapped to have full integrated over MIDI CC with
Transport out Off
Tracker Minis selected instruments. Play can
Notes In MIDI In jack
control Tracker Mini with the pads.
Notes in channel CH1
MIDI out Off
CC in MIDI In jack
CC in channel CH1
Middle C C-5
Clock sync delay 0.0
MIDI OUT
Other MIDI Devices can be used with Tracker Mini's
MIDI Synthesizer mode to control the instruments.
260
MIDI OUT
Beatstep Pro
Polyend Tracker Mini Manual
NOTES NOTES
Polyend Tracker Mini Manual
While integration with Polyend Play is a build in feature for mapping Play's
controls, other MIDI controllers can also be used with an Instrument
Synthesiser accessed through the Instrument Parameter page.
Instrument Synthesizer Mode
Select the Instrument Parameter page using [2] or from the [Menu]. The
1 2 3 4
Instrument Synthesizer, accessed with [More] then [Instrument Synthesizer].
Instrument Parameters 1/2 Instrument Effects
Instrument Parameters 1/2 0m:00s P1.008 1.Analog 3 18p Instrument Effects
Disabled
Low-pass
High-pass
Band-pass
Overdrive Bit depth Reverb send
Volume Panning Tune Finetune Filter Type Cutoff Resonance More
10.00 dB -25 0 0 Low-pass 100 0 0 16 -inf dB
Instrument Synthesizer 0m:00s P1.008
Note: To use Tracker as a synthesizer, the sequence must be stopped.
Tune = 5 1. Strange Sample Number 1
FineTune = 3 2. Guitar
Volume = 7 3. Transient Kick
Panning = 10 4. Snare One
Filter type = 9 5. Closed Hat 1
Cutoff = 1 6. Selection0001
Resonance = 11 7.
Overdrive = 12 8.
Bit Depth = 13 9.
Reverb Send = 14 10.
Delay Send = 15 11.
Volume Automation Type = 20 12.
Volume Attack - Shape LFO = 21 13.
CC List
The left window will display, as a The right window will allow selection of
reference, the Tracker Mini parameter the instrument to control. The instrument
MIDI CC numbers. selected will be shown in the top bar.
Notes on using MIDI Synthesiser Mode:-
• The external device must be configured to match the MIDI
Synthesizer CC controls and general Tracker Mini MIDI
configuration, i.e. Channel etc.
• Tracker Mini's sequencer must be stopped to use as a MIDI
synthesizer.
• The Instrument Synthesizer mode page does not have to be
displayed to operate. The last selected instrument will be the one
used for the synthesizer control from an external controller.
11
MIDI
0m:00s P1.008 1.Analog 3 18p
Delay send Instrument Back
-inf dB Synthesizer
2. Guitar
Instruments
