Polyend Tracker Mini Manual page 91

8
Audio
8.1 Master Pages - Audio Control
Audio is controlled in the Master pages of which 3 are available and
selected by default with button [4]. This is where the Tracker Mini mixer is
found to control the audio levels and also the master effects. This section
will concentrate on the audio level and routing controls. The Master effects
are covered in another section.
Master - Page 1
The Master mix is the first page in the master pages and contains the main
output level as well as a series of effects and gives access to the master
reverb and delay effects. Rendered audio exports of the 'master' i.e. all
tracks, uses the volume level and functions in Master page 1.
Master Page
Page 1 of 3
Master 1/3 0m:00s P1.008
Hard Clip
Soft Clip
Saturate
Overdrive
Drive+
Volume Reverb Delay Limiter EQ Saturation
Soft Clip
-33.08 dB
Volume
Master output level
applied to the main
'Out' connection
Master Effect Pages
Access to the master delay,
reverb, limiter & EQ
parameter pages.
Function Command
Navigate Options Press (Left) or (Right)
Edit Parameter With option selected, Press (Up) or (Down) or [+] / [-]
Select Effect Page Press the Screen Buttons 2 [Reverb], 3 [Delay], 4 [Limiter] or 5 [EQ].
Quick Level Adjust Hold [4] + [+] or [-]. Button [4] is by default, assigned to Master Page.
180
Bass Boost Space
5 1
Master Output Effects
Bass boost, Space and
Saturation single parameter
effect settings.
Polyend Tracker Mini Manual
NOTES NOTES
Polyend Tracker Mini Manual
Track Mixer - Page 2
This Master page controls the track volume levels. Press [4] to cycle
through each page. Each of the 8 tracks is displayed with a real time bar
meter with the current setting in the bar and the specific value shown in the
track label. Tracks rendered as individual stems will use the levels set for
tracks. Note that track names can be edited in this page by pressing [Rec].
Track Mixer
Page 2 of 3
Muted tracks are dimmed
Track Mixer 2/3 0m:00s P1.008
Track 1 Track 2 Track 3 Track 4 Track 5
0.00 dB 0.00 dB 0.00 dB 0.00 dB 0.00 dB
Mute Mute Unmute Mute Mute
Level Adjustment
Adjustable level setting for
track. Bar graph and value
displayed. Also controllable
by MIDI CC71-CC82
Mute State
Screen button sets mute /
unmute state. Also sets solo
/ un-soloed with shift.
Function Command
Adjust Track Level Hold Track Screen Button 1-8 + Press (Up) or (Down) or [+] / [-]
Mute Track Press Track Screen Button 1-8 to toggle Mute / Unmute
Unmute Track Press Track Screen Button 1-8 to toggle Mute / Unmute
Solo Track Hold [Shift] + Press Track Screen Button 1-8 to toggle Solo on/off
Edit Track Names Press [Rec], Edit Mode. Press Track Screen Button 1-8 for track to rename.
Mute Button Behaviour.
In the master section mute is applied when the button is released after being pressed. This is different to muting
in the Pattern section where mutes are applied immediately when the button is pressed.
8
Audio
Tracks & Track
Names
Track 6 Track 7 Track 8
0.00 dB 0.00 dB 0.00 dB
Unmute Unmute Mute
Actual Level
Actual audio level for track. High
levels indicate red, medium
yellow, lower levels green.
181
