Polyend Tracker Mini Manual page 50

5
Sequencing Steps
5.10 FX Step Parameters
Each step event has two FX slots which can be populated from a library of
effects. Each FX has two parts, firstly the effect type, represented by a
single character and secondly it's value.
FX Summary
FX1 & FX2 parameter each has a dedicated
FX1 FX 2
button when working in the pattern.
FX1 FX2
C5 02 V 10 P 25 FX are the third and fourth parameters in the
step event and are highlighted when selected.
V 10
FX Value
FX Type
Pattern 1 0m:00s P1.008 Fx
1 C5 40 ---- P-25 C5 40 ---- H-25 Sets the Volume of an C5 40 ---- P-20 C5 40 ---- P-25 - - None
C5 02 ---- P-20 Instrument. For MIDI C4 12 ---- A 4 C5 40 ---- P-25
2 C5 40 ---- P-25 ! - Off
instruments this sends
3 -- --- ---- ---- -- --- ---- ---- -- --- ---- ---- -- --- ---- ---- V - Volume
the NOTE ON velocity
4 -- --- ---- ---- -- --- ---- ---- -- --- ---- ---- -- --- ---- ---- P - Panning
parameter
5 -- --- ---- ---- -- --- ---- ---- -- --- ---- ---- -- --- ---- ---- M - Micro Tune
6 -- --- ---- ---- -- --- ---- ---- -- --- ---- ---- -- --- ---- ---- G - Glide
7 -- --- ---- ---- -- --- ---- ---- -- --- ---- ---- -- --- ---- ----
T - Tempo
From 0% - 100%
8 -- --- ---- ---- -- --- ---- ---- -- --- ---- ---- -- --- ---- ----
I - Swing
9 -- --- ---- ---- -- --- ---- ---- -- --- ---- ---- -- --- ---- ----
m - Micro Move
10 -- --- ---- ---- -- --- ---- ---- -- --- ---- ---- -- --- ---- ----
q - Gate Length
-- --- ---- ---- -- --- ---- ---- -- --- ---- ---- -- --- ---- ----
11 C - Chance
-- --- ---- ---- -- --- ---- ---- -- --- ---- ---- -- --- ---- ----
12 R - Roll
13 -- --- ---- ---- -- --- ---- ---- -- --- ---- ---- -- --- ---- ---- A - Arp
14 -- --- ---- ---- -- --- ---- ---- -- --- ---- ---- -- --- ---- ----
n - Random Note
15 -- --- ---- ---- -- --- ---- ---- -- --- ---- ---- -- --- ---- ----
i - Random Instrument
Render Invert Duplicate Expand Shrink Copy Paste
Selection Pattern Description
Pattern Pattern Pattern Pattern
While holding [FX1] or [FX2], the pop-up window
will display the available effects list where the
selection can be made to load to the step event.
Tap to select [FX1] or [FX2]. To edit the value, Use [+] / [-] to
adjust the value. The outer [+] / [-] buttons change the value
in larger increments.
98
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
More
Polyend Tracker Mini Manual
NOTES NOTES
Polyend Tracker Mini Manual
Sequencing Steps
▌ DETAILED APPLICATION OF AN EFFECT TO AN EMPTY STEP
1. Press [1] to select the pattern mode page.
2. Select a blank or existing step event.
3. Press [FX1] or [FX2] to ensure the FX parameter is selected in the step
event. This is a short press. Holding [FX1] or [FX2] will display the effect
list pop-up.
4. Select recording mode, Press [Rec]. The steps selected will appear red
as opposed to green when in normal playback mode.
5. To assign the FX to an empty step, either:-
• Hold [FX1] or [FX2] till list appears then release. This will place the
current effect into the step. Press [+] / [-] to adjust the FX value. The
Outer buttons in larger increments.
• Hold [FX1] or [FX2] + (Up) or (Down) to select the type from the list.
Release the [FX1] or [FX2] button, the FX step remains selected.
Press [+] / [-] to adjust the FX value. The Outer buttons in larger
increments.
• Hold [FX1] or [FX2] + [+] or [-] to select the type from the list.
Release the [FX1] or [FX2] button, the FX step remains selected.
Press [+] / [-] to adjust the FX value. The Outer buttons in larger
increments.
6. To assign or change the FX to an existing step, either:-
• Hold [FX1] or [FX2] + (Up) or (Down) to select the type from the list.
Release the [FX1] or [FX2] button, the FX step remains selected.
Press [+] / [-] to adjust the FX value. The Outer buttons in larger
increments.
• Hold [FX1] or [FX2] + [+] or [-] to select the type from the list.
Release the [FX1] or [FX2] button, the FX step remains selected.
Press [+] / [-] to adjust the FX value. The Outer buttons in larger
increments.
7. Subsequent selection of FX slots allow adjustment of its value with the
[+] and [-] buttons when in [Rec] mode.
In the Effect list window, press the 7 th and 8 th screen button to toggle the
description of the highlighted effect on or off. This is an aid to using the FX.
