Polyend Tracker Mini Manual page 127

11
MIDI
11.4 MIDI Instrument Overview
Tracker Mini has a series of MIDI Instruments that can be assigned to steps
in a pattern. MIDI is defined per step, not per track, so MIDI and Audio
instruments can reside on the same track in the same pattern. A MIDI
instrument essentially defines the MIDI channel on which to transmit data
out and also gives access to the instruments MIDI parameters.
The instrument selection has a dedicated
Instr
button when working in the pattern.
C5 M02 - - - - - - - -
Instruments 51-66 constitute the preset MIDI Instruments. Each of
M02
these represents a MIDI channel 1-16. A MIDI instrument is tagged
with an 'M' in the step configuration.
The instrument parameters are accessible directly and are specific
to the currently selected instrument and it's MIDI Channel.
MIDI Instrument Parameters 51. MIDI Channel 1
73 0 Bank 0 Bank 0 Bank 52 116
74 1 ModWh 1 ModWh 1 ModWh 53 117
75 2 Brth 2 Brth 2 Brth 54 118
76 3 3 3 55 119
77 4 Foot 4 Foot 4 Foot 56 120 SOff
78 5 Glide 5 Glide 5 Glide 57 121 Rst
79 6 Data 6 Data 6 Data 58 122 Locl
80 7 ChVol 7 ChVol 7 ChVol 59 123 NOff
81 8 Balnc 8 Balnc 8 Balnc 60 124
82 9 9 9 61 125
83 10 Pan 10 Pan 10 Pan 62 126
84 Porta 11 Exp 11 Exp 11 Exp 63 127
85 12 12 12 64 Sust Prg Chg
86 13 13 13 65 Port Chan AT
Velocity Offset CC A CC B CC C CC D CC E CC F
127 0 74 5 7 11 64 117
CC Outputs
Configure the 6 CC Outputs A-F,
used from a step FX1 or FX2
The default velocity to send out can be applied as well as MIDI Latency compensation in the Offset parameter
This illustration shows several MIDI instruments set for MIDI Channel 2. The notes values will be sent on the
defined channel to a connected device such as another synth or DAW. MIDI Out would need to be set correctly
in the Config > MIDI parameters to transmit the note values over MIDI.
The MIDI transmitted will be based on the project tempo. Also remember that tempo FX can be applied to steps
which would also affect the MIDI output timing.
252
52. MIDI Channel 2
P-20 Track 4 -- --- ---- ---- 1
A 4
-- --- ---- ---- 2
---- C5 M02 ---- ---- 3
A 4
-- --- ---- ---- 4
Polyend Tracker Mini Manual
NOTES NOTES
Polyend Tracker Mini Manual
The Instrument parameters will reflect the MIDI output options available
when selecting a step with a MIDI instrument configured. The Note is set in
the step and will be sent on the channel defined in the MIDI instrument. The
default velocity can also be set for MIDI out.
The same general process is followed when working with MIDI steps as
with audio steps. More details are covered in a prior section.
▌ CREATING A MIDI NOTE OUTPUT STEP
1. Press [1] to select the Pattern Mode page.
2. Select the target step to edit. Use (Up), (Down) to scroll top to bottom.
Press (Left), (Right) to select a track. Example Row 1 of Track 1. The
step should be highlighted with the green bounding box.
3. Press [Rec] to switch to recording mode. The step bounding box will
turn red and allow editing of the step.
4. Note: Hold [Note] + [+] / [-] to set a note for the step.
Also with the note already selected, use [+] / [-] to change it's value.
5. Instrument: Hold [Instrument] + [+] / [-] or (Up) (Down) to change to an
instrument from the 51 to 61 list. Each one will represent a MIDI
channel where the step messages will be transmitted. The Instrument
will be indicated with an 'M' in the instrument slot for the step.
Instrument # Name
51 MIDI Channel 1
52 MIDI Channel 2
53 MIDI Channel 3
54 MIDI Channel 4
55 MIDI Channel 5
56 MIDI Channel 6
57 MIDI Channel 7
58 MIDI Channel 8
59 MIDI Channel 9
60 MIDI Channel 10
61 MIDI Channel 11
62 MIDI Channel 12
63 MIDI Channel 13
64 MIDI Channel 14
65 MIDI Channel 15
66 MIDI Channel 16
11
MIDI
Step Tag MIDI Channel
M01 1
M02 2
M03 3
M04 4
M05 5
M06 6
M07 7
M08 8
M09 9
M10 10
M11 11
M12 12
M13 13
M14 14
M15 15
M16 16
253
