Architecture
2.2 Tracker Mini Audio Structure
Micro SD Card
Firmware
A correctly formatted SD Card must be installed to
Games
operate Tracker Mini. Card default folders shown.
Tracker Mini
Project Project
Project
Loaded Project
Pattern
Maximum 255 Patterns per Project
..... 8 Tracks / Voices per Project .....
Track 1
Step 1 Note Instrument FX1 FX2
Mix
Step
Step 128
MIDI Engine &
Parameters
Track 1
Song
Pattern
Saturation
Pattern Limiter
Space
Pattern
Delay Reverb
Bass Boost
Pattern
EQ
Pattern
Pattern
26
Instruments Mod TrackerLog
Manual Projects Samples
100 Projects are visible and accessible from within Tracker Mini.
More than 100 could be stored on the SD Card.
Instrument Audio Engine
Maximum 48 Instrument slots are available per Project
Track 8
Instrument
Instrument +
Instrument
Delay Reverb
Mix & Pan
Send & Return Send & Return
Filter
Overdrive
Bit-crusher
Wavetable Sample Granular
FX Applications
A variety of effects are selectable from the list of 29 FX.
FX E.g. G
FX E.g. T
FX
E.g. m
Track 8
Sampler
Mic In
Master
Line in
MIDI In
MIDI Out
Out Right
Out Left
Polyend Tracker Mini Manual
2.3 SD Card Structure.
NOTES
The Micro SD Card is an integral part of Tracker Mini and must be inserted
to operate correctly. An alert message is displayed if Tracker Mini is
powered up without an SD Card installed. It is important that the correct
format is applied to the Micro SD Card. This should be FAT32 with Master
Boot Record (MBR) Partitioning.
The default file structure will expand as different functions are used. For
example a snapshots folder is created when capturing screen images, also
export and recording folders created once these files are firstly generated.
Files and folders can be accessed with a PC or Mac. A USB adapter is
supplied with Tracker Mini.
Micro SD Can be connected to a
Root
Polyend Tracker Mini Manual
Architecture
PC / Mac with the USB adapter.
2
27
