Audio
8.10 Audio Output Over USB
The Tracker Mini can send audio out over a connected USB connection.
This will send 12 stereo channels out to the connected device. The
configuration is automatic within the Tracker Mini and any compatible
device connected to the USB connection will be able to access the audio
channels from Tracker Mini.
Channel Outputs Command
1 1 & 2 Master Output
2 3 & 4 Track 1 Stereo Audio Output
3 5 & 6
Track 2 Stereo Audio Output
4 7 & 8 Track 3 Stereo Audio Output
5 9 & 10
Track 4 Stereo Audio Output
6 11 & 12 Track 5 Stereo Audio Output
7 13 & 14 Track 6 Stereo Audio Output
8 15 & 16
Track 7 Stereo Audio Output
9 17 & 18 Track 8 Stereo Audio Output
10 19 & 20 Reverb Stereo Audio Output
11 21 & 22
Delay Stereo Audio Output
12 23 & 24 Reserved
Aggregate Device
To ensure compatibility with the USB Audio features of Tracker Mini it is
highly recommended to use a Mac or PC set up with an aggregate device.
An aggregate device is a virtual interface created on the PC or Mac to
integrate several audio in and out elements together. This overcomes any
issues with multiple / separate devices used for inputs and outputs to a PC
or Mac and allows audio software such as a DAW to connect seamlessly.
The process of setting up an aggregate device may differ depending on the
OS of the PC or Mac and also the connected devices. A general guide is
provided here as reference only.
212
NOTES
Polyend Tracker Mini Manual Polyend Tracker Mini Manual
NOTES
▌ CREATING AN AGGREGATE DEVICE - MAC
1. Ensure Tracker Mini is connected to the Mac via the USB connection.
2. Select and open the 'Finder' function on the Mac.
3. With the finder page open and selected, choose from the main header
menu 'Go' > 'Utilities'.
4. Double click on the 'Audio MIDI Setup' icon from within the presented
utility options page.
5. The audio device page will open. This should show all connected
devices in the left window pane and will include the Tracker Mini as well
as the Mac's integrated speakers and microphone.
6. Click '+' in the lower left corner and choose 'create aggregate device'.
7. A new device is created and the selection boxes will be presented.
Check the boxes of the devices to add to the aggregated device. For
example Tracker Mini and Speakers.
8. Click the name in the left window to rename the device if required.
9. Once the device has been created this will appear in a DAW's audio
interface options, for example 'Audio input' and 'Audio output' options in
Ableton Live Audio settings.
10. This aggregated device should be the chosen option to interface the
Tracker Mini to the Mac Audio. This will handle all the available inputs
from Tracker Mini as well as the audio outputs on the Mac for example
output audio to the internal speakers.
