Polyend Tracker Mini Manual page 129

11
MIDI
The MIDI CC outputs in the Instrument Parameters list follows MIDI standards. Many of the CC's
are undefined. Check the MIDI configuration for any connected devices to know what CC will affect
which parameter. This list is available for each of the 6 CC Assignments A - F. Also the Program
Change 128, Channel Aftertouch 129 and Polyphonic Aftertouch 130 can also be configured here.
CC # Function CC # Function
0 Bank (MSB) 32 Bank (LSB)
1 33
Mod Wheel (MSB) Mod Wheel (LSB)
2 Breath Control (MSB) 34 Breath Control (LSB)
3 35
4 Foot Pedal (MSB) 36 Foot Pedal (LSB)
Glide (MSB) Glide (LSB)
5 37
Portamento Rate Portamento Rate
6 Data Entry (MSB) 38 Data Entry (LSB)
7 Channel Volume (MSB) 39 Channel Volume (LSB)
8 L/R Balance (MSB) 40 L/R Balance (LSB)
9 41
10 Pan (MSB) 42 Pan (LSB)
11 Expression Pedal (MSB) 43 Expression Pedal (LSB)
12 44
13 45
14 46
15 47
16 48
17 49
18 50
19 51
20 52
21 53
22 54
23 55
24 56
25 57
26 58
27 59
28 60
29 61
30 62
31 63
256
CC # Function CC # Function
64 Sustain 96 Data Increment +
65 97
Portamento Data decrement -
66 Sostenuto 98 NRPN LSB
67 Soft Pedal 99 NRPN MSB
68 Legato 100 RPN LSB
69 101
Hold 2 RPN MSB
70 102
71 103
72 104
73 105
74 106
75 107
76 108
77 109
78 110
79 111
80 112
81 113
82 114
83 115
84 116
Portamento Amount
85 117
86 118
87 119
88 High Definition Velocity 120 All sound off
89 121 Reset all
90 122
Local On / Off
91 123
All notes off
92 124
93 125
94 126
95 127
Polyend Tracker Mini Manual
NOTES
▌ CREATING A MIDI CC OUTPUT STEP
1. Ensure the Config > MIDI settings are set to send MIDI. Use [Shift] + [4]
or [Menu] to select the configuration options.
2. Press [1] or select from [Menu] the Pattern Mode page.
3. Select the target step to edit. Use (Up), (Down) to scroll top to bottom.
Press (Left), (Right) to select a track. Example Row 1 of Track 1. The
step should be highlighted with the green bounding box.
4. Press [Rec] to switch to recording mode. The step bounding box will
turn red and allow editing of the step.
5. Hold [Instrument] + Press [+] / [-] or (Up) (Down) to select a MIDI
instrument from listed options 51 to 66. Each will represent a MIDI
channel to transmit the step messages. The Instrument will be indicated
with an 'M' in the instrument slot for the step. Example M01.
6. Hold [FX1] or [FX2] + Press [+] / [-] or (Up) (Down) to set a CC for the
step. This will be one of the 6 options a-f. The selected option will show
as a lower case letter in the step FX slot. Example: 'a' is MIDI CC A.
7. With the FX selected, Press [+] / [-] to set it's CC value. A series of steps
could for example be filled with a ramp up of values. This can be
changed later. Example: Set to 50.
8. Press [2] to select the 'Instrument Parameter' page. MIDI message
options are presented given the instrument is a MIDI Channel.
9. Press a screen button to select a CC Slot that matches the FX
selection. Example, Press [CC A], 3
CC A selected in step 6 above.
10. Press [+] / [-] or (Up) (Down) to scroll the CC parameter lists. Highlight
with the bounding box the CC number to assign. This would typically be
based on the MIDI CC configuration on a receiving device. Example:
CC 74 is Filter Cutoff on Elektron's Digitakt.
11. In this example, CC Number 74 (set in step 10 above) will transmit a CC
value of 50 (set in step 7 above) over MIDI Channel 1 (set in step 5
above) when the selected step is triggered.
Polyend Tracker Mini Manual
11
MIDI
rd
Screen button to match the MIDI
257
