Polyend Tracker Mini Manual page 61

6
Instruments
6.8 Loop Play Modes
Three loop playback modes exist, forward loop, backward loop and
pingpong loop. All of these three play modes have similar functions and
only differ in their playback direction.
The note value, tempo and pattern length will also affect how the sample
plays. A higher note value will play the sample faster. A lower note value will
play the sample slower. Triggering the instrument step will trigger the sample
once and it will continue to play for its duration in loop until another trigger is
initiated or the pattern ends.
Time
Steps 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
S LS
Sample
Forward
Loop
Sample plays forwards from start to the end, then restarts back to the start.
Playback continuously loops start to end until another trigger or the pattern ends
Backward
Loop
Sample plays from the start position to the loop end, then restarts from the loop
end, playing in reverse. Playback continuously loops in reverse within the loop
start / end points until another trigger or the pattern ends
Pingpong
Loop
Sample plays from the start position to the loop end, then plays in reverse to the
the loop start, then plays forwards to the loop end. Playback continuously loops
forward and backwards through this cycle until another trigger or the pattern ends
Sample playback is initially triggered and while ever the pattern plays it will continue to loop.
120
LE E
1 st Cycle & Loop
1 st Cycle
Loop
st
1 Cycle
Loop
Polyend Tracker Mini Manual
NOTES NOTES
Polyend Tracker Mini Manual
Loop Parameters
The parameters for the forward loop, reverse loop and pingpong loop play
are identical across these play modes. Options are start / loop start, end /
loop end plus the zoom visual aid. Navigate and select using the Screen
Buttons. Also navigate using the (Left) (Right) buttons to select the
parameter and (Up) (Down) or [+] / [-] to adjust the value.
Sample Playback 0m:00s P3.002
Zoom
Start Loop Start
Forward Pingpong
Preview Start Loop Start Loop End End
0.000s 0.000s 1.400s 4.700s 6.000s
Screen
Function Parameter Range Description
Button
Selects the play mode to apply. Includes forward
Edit Play Mode 7th & 8th Modes loop, backward loop, pingpong loop as well as 1-
Shot and wavetable / granular synths.
Zooms in horizontally to the visual display for more
precise editing. Does not affect playback. Zoom
Aid Zoom 6th
Variable
reference point is based on the previously adjusted
parameter i.e. Start.
Hold to play the sample. The number below the
screen button label indicates current play position
Aid Preview 1st Variable
in seconds. Preview playback will run for approx 1
sec after releasing the preview button.
Adjusts and edits the sample start point. This is the
starting position when the sample is first triggered
* Lower
Edit Start 2nd
than End in a pattern or when previewed. Red marker turns
green if a zero crossing point is detected.
Adjusts the sample loop start point. This is the start
position used on the 2
* Higher
Edit Loop Start 3rd cycles, playing from loop start to loop end. Value
than Start
will always be same or higher than start position.
Red marker turns green at a zero crossing point.
Adjusts the sample loop end point. This is the end
* Lower position used for playing a loop. Value will always
Edit Loop End 4th
than start be same or lower than end position. Red marker
turns green at a zero crossing point.
Adjusts and edits the sample end point. The
* Higher ending position, outside of a loop when a sample is
Edit End 5th
than Start triggered in a pattern or when previewed. Red
marker turns green at a zero crossing point.
* Start / End, Loop Start / End Positions cannot cross over. Start is always before end.
6
Instruments
16.hh3
1-Shot
Forward loop
Backward loop
Pingpong loop
Slice
Beat Slice
Wavetable
Granular
Loop End End
Backward
Zoom Play Mode
1.00
nd
and subsequent playback
121
