Polyend Tracker Mini Manual page 118

10
Master Effects
10.3 Master Delay
Delay is one of the two send effects. A send effect basically routes an
adjustable amount of audio in parallel to its main signal path and is sent to
a common audio effect. In this case delay. This delay affected audio is then
returned back to the main audio path. The effect itself is a common
function, managing several send / return signals. Any common delay
parameter adjustments will therefore also affect other send signals. The
'Send / Return' configuration is a common application for delay effects.
What is a delay effect?
Delay Time
Time delay between input and output.
Delay Line
Input
Connecting the output to the input creates feedback
and increases the delay 'events'.
A delay is a common production effect used to delay an incoming signal to
the output. While this is a simple principle there are many effects that use
delay as a foundation. Some examples are echo (creating defined repeats)
and chorus (short delay taps to give a thicker rather than echo style feel) as
well as specific delay types such as ping-pong delay, spreading the delay
points across the stereo field left to right and slap-back delay emulating old
tape delays which are used successfully to thicken vocals.
Delay is a time based effect and synchronisation (or not) with the track
tempo should also be considered depending on the output required.
▌ ACCESSING MASTER DELAY PARAMETERS
1. Press [4] or use [Menu] to select master section. Press again if needed,
until the 'Master' Page 1/3 is displayed.
2. Press [Delay], 3 rd Screen button.
3. The six delay parameters are presented on the master delay page.
th
4. Press [Back], 8 Screen button to return to the master page.
234
NOTES
Output
Polyend Tracker Mini Manual
NOTES
Master Delay Page
Accessed via the Master page 1/3 and selected from the screen buttons.
Pingpong
Selects a pingpong (left / right
stereo effect) or standard
when off, delay.
Sync
Synchronisation to project tempo.
If on rate is used to sync to
tempo. Specific time is used if off.
Rate
Synchronisation to tempo,
used when sync is on.
Master Delay Settings.
Option Range
Pingpong On, Off
Sync On, Off
Rate See Rate Table
Time 1 - 3500ms
Feedback 0-99
Filter 100Hz - 20000Hz
Rate Options
8 6 4
1/3 1/4 3/16
Polyend Tracker Mini Manual
Master Effects
Master Delay 0m:00s P3.002
On On 8
Off Off 6
4
3
Filter
2
3/2
Filter applied to the
1
delay effect
3/4
1/2
3/8
1/3
1/4
3/16
1/6
PingPong Sync Rate Time Feedback Filter Back
Off Off 8 500 ms 47 20000Hz
Feedback
Amount of delay output fed
back into the delay line input
Time
Stand alone delay time, used
when sync is off.
Description
Toggles the pingpong mode on or off. This will
set the delays to be generated across the
stereo field left to right
Toggles synchronisation to the project tempo
on or off. When on, the rate with respect to
tempo is used for the delay. When off, the time
parameter is used.
The rate divider / multiplier, synchronised to
project tempo, used for the delay time.
Available when sync is set to on.
The time used for the delay. Only available
when sync is set to off.
Amount of delay output signal that is fed back
into the delay input. This parameter is what
increases the number of delays in the audio.
Applies a filter to the delay and helps shape
the sound tone more appropriately.
3 2 3/2 1 3/4 1/2
1/6 1/8 1/12 1/16 1/24 1/32
10
3/8
235
