Polyend Tracker Mini Manual page 89

7
FX Steps
7.38 MIDI Messages
FX Type Tag Effect
a - f MIDI CC A-F Messages
FX Description
Issues MIDI output messages. These can be CC (Control Change), PC
(Program Change), Polyphonic Aftertouch or Channel Aftertouch selectable in
the Instrument Parameters. Requires a MIDI instrument set with the channel.
Value Ranges
0-127
Example
While the glide effect operates on a time based pitch change and is referenced
from the previous step, the slide function operates using semitone increments
to control pitch from the current step note value. Values in denominations of 16
represent semitones.
1 C5 18 ---- ----
Sends a CC Value of 24 to MIDI Channel 1.
C6 M01 a 24
5 ----
Parameter to control is set in 'Instrument Parameters'
--- -- ---- ----
9
13 C6 18 F 32
---- ----
16 --- -- ---- ----
Mod Wheel.
The destination parameter is defined in the instrument
parameter settings when a MIDI Instrument is used.
0 Bank
1 ModWh
2 Brth
3
4 Foot
5 Glide
6 Data
7 ChVol
8 Balnc
9
10 Pan
11 Exp
12
13
CC A
1
MIDI Message to control external device.
176
NOTES
FX1 or FX2 + Value
a 24
CC Value to send
Range 0 - 127
Instrument
M01
MIDI Channel 1
Max 16 MIDI Instruments, each
can host up to 6 CC Values
Polyend Tracker Mini Manual
7.39 MIDI Chords
NOTES
FX Type Tag
0
FX Description
Sends MIDI Chords out which are a combination of notes based on the
numerical (Hex) value of the step FX. MID Chord is also used in conjunction
with Arp step FX.
Value Ranges
Various
Example
The chord is derived from the hexadecimal value applied in the MIDI Chord
step and selected from a defined library of chords. The first '0' represents the
MIDI Chord effect other digits the chord notes, offset from the root note.
1 C5 18 ----
C6 18
5 ----
9 --- -- ---- ----
13 C6 18
---- ----
16 --- -- ---- ----
Hexadecimal to Decimal Converter
Hex 1 2 3
Dec 1 2 3
Tracker Mini Chords (Root C Examples)
Scale
MIDI Chord
Hex Code
0 27 Sus2
0 28 Sus2 #5
0 36 DimTriad
0 37 Min
0 47 Maj
0 48 AugTriad
0 57 Sus4
0 5A Stack4
0 5C Open4
0 67 Sus #4
0 7C Open5
0 7E Stack5
0279 Sus2Add6 C - D - G - A
027A Sus2 b7
027B Sus2Maj7
Polyend Tracker Mini Manual
FX Steps
Effect
MIDI Chords Out
0 47
Triggers a Major Chord: C5 + 4 Semitones + 7 Semitones.
Triggers a C6 Note.
----
Hex code represents
+ Semitones from root
F112
0 47
e.g.
Maj C E G
0 +4 +7
4 5 6 7 8 9 A B C D E F
4 5 6 7 8 9 10 11 12 13 14 15
Scale
Chord MIDI Chord Chord
Example from Root C Hex Code Example from Root C
C - D - G 0368 Dim7 C - D# - F# - G#
C - D - G# 036A Half Dim C - D# - F# - A#
C - D# - F# 0378 Min b6 C - D# - G - G#
C - D# - G 0379 Min6 C - D# - G - A
C - E - G 037A Min7 C - D# - G - A#
C - E - G# 037B MinMaj7 C - D# - G - B
C - F - G 0479 Maj6 C - E - G - A
C - F - A# 047A Dom7 C - E - G - A#
C - F - C 047B Maj7 C - E - G - B
C - F# - G 0489 Aug Add6 C - E - G# - A
C - G - C 048A Aug b7 C - E - G# - A#
C - G - D 048B Aug Maj7 C - E - G# - B
057A Sus b7 C - F - G - A#
C - D - G - A# 057B Su4Maj7 C - F - G - B
C - E - G - B
7
177
