Instruments
6.10 Wavetable Play Modes
Wavetable instruments can be created in Tracker Mini. This emulates
classic wavetable synthesizers by using a sample as the wavetable source.
Standard Tracker Mini samples can be used 'out of the box' or samples
prepared specifically to suit the application in a wavetable synth and give
better performance. The Tracker Mini wavetable synthesis brings a simple
yet different creative option into the instrument library.
What is Wavetable Synthesis?
The most common synth model is subtractive synthesis. This is based on a
sound source, typically using one or more oscillators, tuned in various
ways. The sound is then shaped and carved by filtering out (subtracting)
frequencies, applying envelopes and adding effects. Wavetable synths
typically follow these same principles but the 'oscillator' is formed from a
series of wave-shapes called wavetables. In reality, a wavetable consists of
a set of stacked samples called frames, the standard being 256 frames.
Navigating or modulating through the almost endless wave positions and
selecting 'single cycles' in the wavetable is a fundamental element in
wavetable sound design. In Tracker Mini the wavetable size (samples per
frame) is set by the 'Window' parameter. Think of this as the length of the
available table, the default maximum being defined by the original audio
sample format. The 'Position' within the wavetable is also selectable and
important in the sound design process. Position can also be modulated.
Sample
Waveform Cycle.
Sample Playback 0m:00s P3.002
Preview Position Window
4 2048
Position Window
Wave position selection, Frame size, range dictated
also can be modulated. by wavetable format
126
NOTES
Current Instrument
Selected
16.hh3
1-Shot
Forward loop
Backward loop
Pingpong loop
Slice
Beat Slice
Wavetable
Granular
Play Mode
Play Mode List.
How the sample will be
played in the instrument
Polyend Tracker Mini Manual
NOTES
Wavetable Parameters
The wavetable play mode is a simplified application of wavetable synthesis
and consists of two core parameters. The Window is the wavetable length
(samples per frame) and has a maximum value based on the original file.
The position parameter is what enables the creative sound design and
audio manipulation. This can be manually adjusted to find a sweet spot or
modulated with the envelope or LFO.
Function Parameter
Edit Play Mode
Aid Preview
Aid Window
Edit Position
Polyend Tracker Mini Manual
Instruments
Size of window will affect resolution
Window
Position
Screen
Range Description
Button
Selects the play mode to apply. Includes
7th & 8th Modes Wavetable and Granular as well as 1-Shot and the
three loop modes.
Hold to play the wave from the current position
1st
selected in the window. Also hold while adjusting
position to 'scan' for the desired sound.
The width of the wavetable can be adjusted down
from the default maximum. The parameters are
3rd Variable
normally divisions of 2 down from the maximum
(Typically 2048)
Selects the playback position within the wavetable
window. This can be manually adjusted to find the
2nd
Variable
desired 'sweet spot' or modulated with an LFO or
Envelope for movement and interest.
