List of diagnostic events

Diagnostic Short text
number
Diagnostic of sensor
003 Broken probe detected
046 Build-up detected
104 HF cable
105 HF cable
106 Sensor
Diagnostic of electronic
242 Software incompatible
252 Modules incompatible
261 Electronic modules
262 Module connection
270 Main electronic failure
271 Main electronic failure
272 Main electronic failure
273 Main electronic failure
275 I/O module failure
276 I/O module failure
282 Data storage
283 Memory content
311 Electronic failure
311 Electronic failure
Diagnostic of configuration
410 Data transfer
412 Processing Download
Diagnostics and troubleshooting
Remedy instructions
1. Check map
2. Check sensor
Clean sensor
and check sealing
1. Dry HF cable connection
2. Change HF cable
1. Tighten HF cable connection
2. Check sensor
3. Change HF cable
1. Check sensor
2. Check HF cable
3. Contact service
1. Check software
2. Flash or change main electronics
module
1. Check electronic modules
2. Change I/O or main electronic
module
1. Restart device
2. Check electronic modules
3. Change I/O Modul or main
electronics
1. Check module connections
2. Change electronic modules
Change main electronic module
1. Restart device
2. Change main electronic module
1. Restart device
2. Contact service
1. Emergency operation via display
2. Change main electronics
Change I/O module
1. Restart device
2. Change I/O module
1. Restart device
2. Contact service
1. Transfer data or reset device
2. Contact service
1. Transfer data or reset device
2. Contact service
Maintenance required!
1. Do not perform reset
2. Contact service
1. Check connection
2. Retry data transfer
Download active, please wait
Status Diagnostic
signal behavior
[from the [from the
factory] factory]
F Alarm
F Alarm
F Alarm
F Alarm
F Alarm
F Alarm
F Alarm
F Alarm
F Alarm
F Alarm
F Alarm
F Alarm
F Alarm
F Alarm
F Alarm
F Alarm
F Alarm
F Alarm
M Warning
F Alarm
C Warning
