Levelflex FMP50 PROFIBUS PA
Channel
Navigation
Description
Selection
Factory setting
Additional information

Out value

Navigation
Description
User entry
* Visibility depends on order options or device settings
Endress+Hauser
16.4.5

"Analog input 1 to 6" submenu

There is an Analog input submenu for each Analog Input Block of the device. Only
the most important parameters of the respective block are available at this position of
the operating menu. For a complete list of the block parameters refer to: Diagnostics
→ Analog inputs → Analog input 1 to 6
Navigation  Diagnostics → Analog inputs → Analog input 1 to 6
 Diagnostics → Analog inputs → Analog input 1 to 6 → Channel
Standard parameter CHANNEL of the Analog Input Block according to the PROFIBUS
Profile.
• Level linearized
• Distance
*
• Interface linearized
*
• Interface distance
*
• Thickness upper layer
• Terminal voltage
• Electronic temperature
• Measured capacitance
• Absolute echo amplitude
• Relative echo amplitude
• Absolute interface amplitude
• Relative interface amplitude
• Absolute EOP amplitude
• Noise of signal
• EOP shift
*
• Calculated DC value
• Sensor debug
• Analog output adv. diagnostics 1
• Analog output adv. diagnostics 2
Level linearized
Allocates a measured value to the AI block.
 Diagnostics → Analog inputs → Analog input 1 to 6 → Out value
Element Value of the standard parameter OUT in the Analog Input Block according to the
PROFIBUS Profile.
Signed floating-point number
*
*
*
Operating menu

183
