Endress+Hauser Micropilot FMR60B Brief Operating Instructions

Endress+Hauser Micropilot FMR60B Brief Operating Instructions

Free-space radar hart
Hide thumbs Also See for Micropilot FMR60B:

Advertisement

Quick Links

Download this manual
KA01587F/00/EN/04.24-00
71687745
2024-12-06
Products
Brief Operating Instructions
Micropilot FMR60B
Free-space radar
HART
These Brief Operating Instructions are not a
substitute for the Operating Instructions
pertaining to the device.
Detailed information can be found in the
Operating Instructions and the additional
documentation.
Available for all device versions via:
• Internet:
• Smartphone/tablet: Endress+Hauser
Operations app
Solutions
www.endress.com/deviceviewer
Services

Advertisement

loading
Need help?

Need help?

Do you have a question about the Micropilot FMR60B and is the answer not in the manual?

Questions and answers

Related Manuals for Endress+Hauser Micropilot FMR60B

Summary of Contents for Endress+Hauser Micropilot FMR60B

  • Page 1 Products Solutions Services KA01587F/00/EN/04.24-00 71687745 2024-12-06 Brief Operating Instructions Micropilot FMR60B Free-space radar HART These Brief Operating Instructions are not a substitute for the Operating Instructions pertaining to the device. Detailed information can be found in the Operating Instructions and the additional documentation.
  • Page 2 Micropilot FMR60B HART Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...
  • Page 3 Micropilot FMR60B HART Symbols Symbols Safety symbols DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. WARNING This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury.
  • Page 4 Requirements for the personnel Micropilot FMR60B HART Requirements for the personnel The personnel for installation, commissioning, diagnostics and maintenance must fulfill the following requirements: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task. ‣...
  • Page 5 Do not touch or clean device surfaces with pointed or hard objects. Clarification of borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability.
  • Page 6  All the information about the measuring device is displayed. ‣ Endress+Hauser Operations app; manually enter the serial number indicated on the nameplate or scan the 2D matrix code on the nameplate.  All the information about the measuring device is displayed.
  • Page 7 Micropilot FMR60B HART Storage and transport • Technical values, e.g. supply voltage, current consumption, ambient temperature, communication-specific data (optional) • Degree of protection • Approvals with symbols • Reference to Safety Instructions (XA) (optional) ‣ Compare the information on the nameplate with the order.
  • Page 8 Installation Micropilot FMR60B HART Installation 11.1 General instructions WARNING Loss of protection rating if the device is opened in a wet environment. ‣ Only open the device in a dry environment! Install the device or turn the housing so that the cable entries do not point upwards.
  • Page 9 Micropilot FMR60B HART Installation 11.2 Installation requirements 11.2.1 Internal vessel fittings α A0031777 Avoid internal fittings (level switches, temperature sensors, struts, vacuum rings, heating coils, baffles etc.) inside the signal beam. Pay attention to the beam angle α. 11.2.2 Vertical alignment of antenna axis Align the antenna so that it is perpendicular to the product surface.
  • Page 10 Installation Micropilot FMR60B HART Maximum nozzle length H as a function of the nozzle diameter D D 50 to 80 mm (2 to 3.2 in) 600 mm (24 in) 80 to 100 mm (3.2 to 4 in) 1 000 mm (24 in)
  • Page 11 Micropilot FMR60B HART Installation The maximum length of the nozzle H depends on the nozzle diameter D D 50 to 80 mm (2 to 3.2 in) 750 mm (30 in) 80 to 100 mm (3.2 to 4 in) 1 150 mm (46 in)
  • Page 12 Installation Micropilot FMR60B HART D 100 to 150 mm (4 to 6 in) 550 mm (22 in) ≥ 150 mm (6 in) 850 mm (34 in) In the case of longer nozzles, reduced measuring performance must be expected. Please note the following: •...
  • Page 13 Micropilot FMR60B HART Installation Your benefits • Easy installation due to optimum alignment of housing • Easily accessible device operation • Optimum readability of the local display (optional) A0046660 Plastic single compartment housing (no locking screw) Aluminum single compartment housing...
  • Page 14 Installation Micropilot FMR60B HART 4 0.7 Nm A0038224 If fitted: release the screw of the cover lock for the electronics compartment cover using the Allen key. Unscrew the electronics compartment cover from the transmitter housing and check the cover seal.
  • Page 15 Micropilot FMR60B HART Electrical connection  Are the securing screws and cover lock tightened securely?  Does the measuring device comply with the measuring point specifications? For example: •  Process temperature •  Process pressure •  Ambient temperature •  Measuring range Electrical connection 12.1...
  • Page 16 Electrical connection Micropilot FMR60B HART 0.7 Nm A0050983  2 Cover with securing screw; hygienic housing (only for dust explosion protection) 12.1.2 Potential equalization The protective ground on the device must not be connected. If necessary, the potential matching line can be connected to the outer ground terminal of the housing before the device is connected.
  • Page 17 Micropilot FMR60B HART Electrical connection 12.2 Connecting the device A0046659 Single compartment housing, plastic Single compartment housing, aluminum, coated Single compartment housing, 316L, hygiene Dual compartment housing, aluminum, coated Dual compartment housing, L-shaped, aluminum, coated Connection compartment cover Devices with a single compartment 316L hygiene housing and conduit screw connection must be connected as end-of-line devices;...
  • Page 18 Electrical connection Micropilot FMR60B HART Cable outer diameter The cable outer diameter depends on the cable gland used • Plastic gland: ⌀5 to 10 mm (0.2 to 0.38 in) • Nickel-plated brass gland: ⌀7 to 10.5 mm (0.28 to 0.41 in) •...
  • Page 19 Micropilot FMR60B HART Electrical connection Connection example of relay A0015909  5 Connection example of relay Connection example for the digital input A0015910  6 Connection example for the digital input Pull-up resistor Digital input Endress+Hauser...
  • Page 20 Electrical connection Micropilot FMR60B HART 12.2.5 Function diagram 4 to 20 mA HART + 4 to 20 mA analog (optional) A0036502  7 Function diagram 4 to 20 mA HART + 4 to 20 mA analog Active barrier for power supply, current output 1; observe terminal voltage Resistor for HART communication (≥...
  • Page 21 Micropilot FMR60B HART Electrical connection Overvoltage category Overvoltage category II 12.2.7 Wiring WARNING Supply voltage might be connected! Risk of electric shock and/or explosion! ‣ If the device is used in hazardous areas, make sure to comply with national standards and the specifications in the Safety Instructions (XAs).
  • Page 22 Electrical connection Micropilot FMR60B HART 12.2.8 Terminal assignment Single compartment housing A0042594  8 Connection terminals and ground terminal in the connection compartment, single compartment housing Positive terminal Negative terminal Internal ground terminal Dual compartment housing; 4 to 20 mA HART A0042803 ...
  • Page 23 Micropilot FMR60B HART Electrical connection Dual compartment housing; 4 to 20 mA HART + 4 to 20 mA analog (optional) A0054875  10 Terminal assignment in connection compartment; 4 to 20 mA HART + 4 to 20 mA analog; dual...
  • Page 24 Electrical connection Micropilot FMR60B HART Dual compartment housing L-shaped; 4 to 20 mA HART A0045842  12 Terminal assignment in connection compartment; 4 to 20 mA HART; dual compartment housing L-shaped Plus terminal 4 to 20 mA HART Minus terminal 4 to 20 mA HART Internal ground terminal Dual compartment housing L-shaped;...
  • Page 25 Micropilot FMR60B HART Electrical connection Dual compartment housing L-shaped; 4 to 20 mA HART, switching output (optional) A0054876  14 Terminal assignment in connection compartment; 4 to 20 mA HART, switching output; dual compartment housing L-shaped Plus terminal 4 to 20 mA HART (current output 1)
  • Page 26 Electrical connection Micropilot FMR60B HART The number and type of cable entries depend on the device version ordered. Always route connecting cables downwards so that moisture cannot penetrate the connection compartment. If necessary, create a drip loop or use a weather protection cover.
  • Page 27 (e.g. FieldCare/DeviceCare). 13.3 Structure and function of the operating menu The differences between the structure of the operating menus of the local display and the Endress+Hauser FieldCare or DeviceCare operating tools can be summarized as follows: Endress+Hauser...
  • Page 28 Operation options Micropilot FMR60B HART The local display is suitable for configuring simple applications. The operating tools (FieldCare, DeviceCare, SmartBlue, AMS, PDM, ...) can be used to configure the parameters of wide-ranging applications. Wizards help the user to commission the various applications. The user is guided through the individual configuration steps.
  • Page 29 Prerequisite • Device with device display including Bluetooth • Smartphone or tablet with Endress+Hauser SmartBlue app or PC with DeviceCare from version 1.07.05 or FieldXpert SMT70 The connection has a range of up to 25 m (82 ft). The range can vary depending on environmental conditions such as attachments, walls or ceilings.
  • Page 30 • Like the password, the reset code can also be changed. • If the user-defined reset code is lost, the password can no longer be reset via the SmartBlue app. In this case, contact Endress+Hauser Service. 13.5 Access to the operating menu via the operating tool Access via the operating tool is possible: •...
  • Page 31 Micropilot FMR60B HART Commissioning The fastest way to configure Endress+Hauser field devices is with the dedicated "DeviceCare" tool. Together with the device type managers (DTMs), DeviceCare presents a convenient, comprehensive solution. For details, see Innovation Brochure IN01047S 13.7 FieldCare 13.7.1 Function range FDT-based plant asset management tool from Endress+Hauser.
  • Page 32 Commissioning Micropilot FMR60B HART  Post-mounting check Post-connection check 14.3 Connecting via FieldCare and DeviceCare 14.3.1 Via HART protocol A0044334  18 Options for remote operation via HART protocol PLC (programmable logic controller) Transmitter power supply unit, e. g. RN42 (with communication resistor)
  • Page 33 Via service interface (CDI) A0039148 Computer with FieldCare/DeviceCare operating tool Commubox Service interface (CDI) of the device (= Endress+Hauser Common Data Interface) 14.4 Configuring the device address via software See "HART address" parameter Enter the address to exchange data via the HART protocol.
  • Page 34 Commissioning Micropilot FMR60B HART Selection in the Language parameter; Visibility depends on order options or device settings 14.6 Configuring the device 14.6.1 Level measurement in liquids 100% A0016933  19 Configuration parameters for level measurement in liquids Reference point of measurement Length of antenna + 10 mm (0.4 in)
  • Page 35 Micropilot FMR60B HART Commissioning 14.6.2 Commissioning with the Commissioning wizard In FieldCare, DeviceCare, SmartBlue and on the display, the Commissioning wizard is available to guide the user through the initial commissioning steps. Complete this wizard to commission the device. For each parameter, enter the appropriate value or select the appropriate option.
  • Page 36 *71687745* 71687745 www.addresses.endress.com...
