Operating menu

Assign measurement variable

Navigation
Selection
Factory setting
Additional information

Value process variable

Navigation
Prerequisite
User entry
Factory setting
Additional information

Switch output simulation

Navigation
Description
Selection
* Visibility depends on order options or device settings
190
Description of parameters
Navigation  Expert → Diagnostics → Simulation
 Expert → Diagnostics → Simulation → Assign measurement variable
• Off
• Level
*
• Interface
• Level linearized
• Interface linearized
• Thickness linearized
Off
• The value of the variable to be simulated is defined in the Value process variable
parameter (→  190).
• If Assign measurement variable ≠ Off, a simulation is active. This is indicated by a
diagnotic message of the Function check (C) category.
 Expert → Diagnostics → Simulation → Value process variable
Assign measurement variable (→  190) ≠ Off
Signed floating-point number
0
Downstream measured value processing and the signal output use this simulation value. In
this way, users can verify whether the measuring device has been configured correctly.
 Expert → Diagnostics → Simulation → Switch output simulation
Switch the simulation of the switch output on and off.
• Off
• On
