The manufacturer reserves the right to modify technical data without prior notice. The Endress+Hauser sales organization will supply you with current information and updates to these instructions. Endress+Hauser...
Micropilot FMR62B HART Table of contents Table of contents 5.3.7 Changing the installation position of About this document ....5 the display module ....20 Purpose of this document .
Page 4
Table of contents Micropilot FMR62B HART Connecting via FieldCare and DeviceCare ..40 Repair ......56 9.3.1...
Micropilot FMR62B HART About this document About this document Purpose of this document These Operating Instructions contain all the information that is required in the various phases of the life cycle of the device: from product identification, incoming acceptance and storage, to mounting, connection, operation and commissioning through to troubleshooting, maintenance and disposal.
• Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate. The following document types are available in the Downloads area of the Endress+Hauser website (www.endress.com/downloads), depending on the device version: Document type Purpose and content of the document...
Page 7
About this document Bluetooth® The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Endress+Hauser is under license. Other trademarks and trade names are those of their respective owners. Apple®...
Do not touch or clean device surfaces with pointed or hard objects. Clarification of borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability.
Micropilot FMR62B HART Basic safety instructions Workplace safety When working on and with the device: ‣ Wear the required personal protective equipment according to federal/national regulations. ‣ Switch off the supply voltage before connecting the device. Operational safety Damage to the device! ‣...
Page 10
Basic safety instructions Micropilot FMR62B HART • Write protection via hardware write protection switch • Access code (applies for operation via display, Bluetooth or FieldCare, DeviceCare, ASM, PDM) Endress+Hauser...
All the information about the measuring device is displayed. ‣ Endress+Hauser Operations app; manually enter the serial number indicated on the nameplate or scan the 2D matrix code on the nameplate. All the information about the measuring device is displayed.
Micropilot FMR62B HART Incoming acceptance and product identification 4.2.2 Manufacturer address Endress+Hauser SE+Co. KG Hauptstraße 1 79689 Maulburg, Germany Place of manufacture: See nameplate. Storage and transport 4.3.1 Storage conditions • Use the original packaging • Store the device in clean and dry conditions and protect from damage caused by shocks Storage temperature range See Technical Information.
Installation Micropilot FMR62B HART Installation General instructions WARNING Loss of protection rating if the device is opened in a wet environment. ‣ Only open the device in a dry environment! 1. Install the device or turn the housing so that the cable entries do not point upwards.
Micropilot FMR62B HART Installation 5.2.2 Avoiding interference echoes A0031813 Metal deflector plates, installed at an angle to scatter the radar signals, help prevent interference echoes. 5.2.3 Vertical alignment of antenna axis Align the antenna so that it is perpendicular to the product surface.
Installation Micropilot FMR62B HART Information about the mounting nozzle The maximum nozzle length H depends on the nozzle diameter D. Maximum nozzle length H as a function of the nozzle diameter D D 80 to 100 mm (3.2 to 4 in)
Micropilot FMR62B HART Installation 5.3.3 Antenna, PTFE cladded, flush mount 50 mm (2 in) The cladding on the antenna also acts as a process seal. An additional seal is not required for installation. Mounting cladded flanges Note the following for cladded flanges: •...
Installation Micropilot FMR62B HART Mounting cladded flanges Note the following for cladded flanges: • Use the same number of flange screws as the number of flange bores provided. • Tighten the screws with the necessary torque (see Table). • Retighten after 24 hours or after the first temperature cycle.
Micropilot FMR62B HART Installation The maximum length of the nozzle H depends on the nozzle diameter D D 80 to 100 mm (3.2 to 4 in) 1 750 mm (70 in) 100 to 150 mm (4 to 6 in) 2 200 mm (88 in) ≥...
Installation Micropilot FMR62B HART 4 0.7 Nm A0038224 1. If fitted: release the screw of the cover lock for the electronics compartment cover using the Allen key. 2. Unscrew the electronics compartment cover from the transmitter housing and check the cover seal.
Page 21
Micropilot FMR62B HART Installation WARNING Supply voltage switched on! Risk of electric shock and/or explosion! ‣ Switch off the supply voltage before opening the measuring instrument. 1 → 2 → 3 → 0.7 Nm A0046831 A0046832 A0046833 ‣ ‣ ‣...
Installation Micropilot FMR62B HART 7 → A0048406 A0046928 ‣ ‣ Plug in the connection for the Screw the display cover firmly display module in the back onto the housing. If fitted: connection compartment. tighten the screw of the cover ‣...
Micropilot FMR62B HART Electrical connection Electrical connection Connecting requirements 6.1.1 Cover with securing screw The cover is locked by a securing screw in devices for use in hazardous areas with certain explosion protection. NOTICE If the securing screw is not positioned correctly, the cover cannot provide secure sealing.
Micropilot FMR62B HART Electrical connection Non-hazardous, Ex d, Ex e 10.5 to 35 V Ex i 10.5 to 30 V Nominal current 4 to 20 mA Power consumption 0.9 W max. The power unit must be safety-approved (e.g. PELV, SELV, Class 2) and must comply with the relevant protocol specifications.
Electrical connection Micropilot FMR62B HART 6.2.4 Function diagram 4 to 20 mA HART, switching output (optional) A0036501 5 Function diagram 4 to 20 mA HART, switching output Active barrier for power supply; observe terminal voltage Resistor for HART communication (≥ 250 Ω); observe maximum load Connection for Commubox FXA195 or FieldXpert (via VIATOR Bluetooth modem) Analog display unit;...
Micropilot FMR62B HART Electrical connection 6.2.5 Function diagram 4 to 20 mA HART + 4 to 20 mA analog (optional) A0036502 8 Function diagram 4 to 20 mA HART + 4 to 20 mA analog Active barrier for power supply, current output 1; observe terminal voltage Resistor for HART communication (≥...
Electrical connection Micropilot FMR62B HART 6.2.7 Wiring WARNING Supply voltage might be connected! Risk of electric shock and/or explosion! ‣ If the device is used in hazardous areas, make sure to comply with national standards and the specifications in the Safety Instructions (XAs). The specified cable gland must be used.
Page 29
Micropilot FMR62B HART Electrical connection Dual compartment housing; 4 to 20 mA HART A0042803 10 Terminal assignment in connection compartment; 4 to 20 mA HART; dual compartment housing Plus terminal 4 to 20 mA HART Minus terminal 4 to 20 mA HART Internal ground terminal Dual compartment housing;...
Page 30
Electrical connection Micropilot FMR62B HART Dual compartment housing; 4 to 20 mA HART, switching output (optional) A0054875 12 Terminal assignment in connection compartment; 4 to 20 mA HART, switching output, dual compartment housing Plus terminal 4 to 20 mA HART (current output 1)
Page 31
Micropilot FMR62B HART Electrical connection Dual compartment housing L-shaped; 4 to 20 mA HART + 4 to 20 mA analog (optional) A0054876 14 Terminal assignment in connection compartment; 4 to 20 mA HART + 4 to 20 mA analog; dual...
Electrical connection Micropilot FMR62B HART 6.2.9 Cable entries A0046584 Single compartment housing, plastic Single compartment housing, aluminum, coated Single compartment housing, 316L, hygiene Dual compartment housing, aluminum, coated Dual compartment housing, L-shaped, aluminum, coated Cable entry Dummy plug The number and type of cable entries depend on the device version ordered.
Micropilot FMR62B HART Electrical connection Measuring instruments with Harting plug Han7D – + – Han7D – A0041011 Electrical connection for devices with Harting plug Han7D View of the plug connection on the device Brown Green-yellow Blue Material • CuZn •...
Page 34
Electrical connection Micropilot FMR62B HART Do the mounted cables have strain relief? Cable glands mounted, securely tightened and leak-tight? Does the supply voltage correspond to the specifications on the nameplate? No reverse polarity, terminal assignment correct? Cover screwed down correctly? Cover lock tightened correctly?
Structure and function of the operating menu The differences between the structure of the operating menus of the local display and the Endress+Hauser FieldCare or DeviceCare operating tools can be summarized as follows: The local display is suitable for configuring simple applications.
Operation options Micropilot FMR62B HART If an incorrect access code is entered, the user obtains the access rights of the Operator role. Access to operating menu via local display 7.4.1 Device display (optional) Possible to operate the optical operating keys through the cover. No need to open the device.
Prerequisite • Device with device display including Bluetooth • Smartphone or tablet with Endress+Hauser SmartBlue app or PC with DeviceCare from version 1.07.05 or FieldXpert SMT70 The connection has a range of up to 25 m (82 ft). The range can vary depending on environmental conditions such as attachments, walls or ceilings.
7.6.1 Function scope Tool for connecting and configuring Endress+Hauser field devices. The fastest way to configure Endress+Hauser field devices is with the dedicated "DeviceCare" tool. Together with the device type managers (DTMs), DeviceCare presents a convenient, comprehensive solution. For details, see Innovation Brochure IN01047S FieldCare 7.7.1...
Micropilot FMR62B HART System integration System integration Overview of device description files • Manufacturer ID: 17 (0x0011) • Device type ID: 0x11C1 • HART specification: 7.6 • DD files, information and files can be found at: • www.endress.com • www.fieldcommgroup.org...
Commissioning Micropilot FMR62B HART Commissioning All configuration tools provide a commissioning assistant that supports the user when setting the most important configuration parameters (Guidance menu Commissioning wizard). Preliminaries The measuring range and the unit in which the measured value is transmitted correspond to the specifications on the nameplate.
Via service interface (CDI) A0039148 Computer with FieldCare/DeviceCare operating tool Commubox Service interface (CDI) of the device (= Endress+Hauser Common Data Interface) Configuring the device address via software See "HART address" parameter Enter the address to exchange data via the HART protocol.
Commissioning Micropilot FMR62B HART Configuring the device 9.6.1 Level measurement in liquids 100% A0016933 20 Configuration parameters for level measurement in liquids Reference point of measurement Length of antenna + 10 mm (0.4 in) 50 to 80 mm (1.97 to 3.15 in); medium εr < 2...
Micropilot FMR62B HART Commissioning Record the current Echo curve as a reference echo curve for subsequent diagnostic purposes. After the measurement has been configured, it is recommended to record the current Echo curve as a reference echo curve. The Save reference curve parameter in the Echo curve submenuis used to record the Echo curve.
The Heartbeat submenu is only available if operating via FieldCare, DeviceCare or the SmartBlue app. It contains the wizards that are available with the application packages Heartbeat Verification and Heartbeat Monitoring. Documentation on the Heartbeat Technology: Endress+Hauser website: www.endress.com → Downloads.
Micropilot FMR62B HART Diagnosis and troubleshooting Diagnosis and troubleshooting 11.1 General troubleshooting 11.1.1 General errors Device is not responding • Possible cause: Supply voltage does not match the specification on the nameplate Remedial action: Apply the correct voltage • Possible cause: The polarity of the supply voltage is wrong Remedial action: Correct the polarity •...
Remedial action: The standard user name is "admin" and the password is the device serial number indicated on the device nameplate (only if the password was not changed by the user beforehand) If the password has been forgotten, contact Endress+Hauser Service (www.addresses.endress.com) Connection via SmartBlue not possible •...
Micropilot FMR62B HART Diagnosis and troubleshooting X X X X X X X X X X X X X X 20.50 S801 Supply voltage Menu A0051136 21 Diagnostic message displayed in alternating sequence with the measured value If two or more diagnostic events occur simultaneously, only the diagnostic message with the highest priority is shown.
Diagnosis and troubleshooting Micropilot FMR62B HART Function check (C) The device is in the service mode (e.g. during a simulation). Out of specification (S) Device operation: • Outside of the technical specifications (e.g. during startup or a cleaning) • Outside of the configuration performed by the user (e.g. sensor frequency outside the...
Micropilot FMR62B HART Diagnosis and troubleshooting 11.4 Remedy informationCalling up 11.4.1 Graphic display with keys 1 → X X X X X X X S801 Supply voltage Menu A0051131 ‣ Open the Diagnostic list submenu 2 → Diagnostic list Diagnostics 1...
Diagnosis and troubleshooting Micropilot FMR62B HART 11.6 List of diagnostic events If Remedy information Contact the Service Department is displayed (www.addresses.endress.com), be ready with the service ID shown. Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the...
Page 51
Micropilot FMR62B HART Diagnosis and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Dataset different 1. Check dataset file Warning 2. Check device parameterization 3. Download new device parameterization Current output 1 to 2 1.
Diagnosis and troubleshooting Micropilot FMR62B HART Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Foam detected Check process conditions Warning Level limited 1. Check level Warning 2. Check limit parameters Diagnostic behavior can be changed.
Micropilot FMR62B HART Diagnosis and troubleshooting 11.7.3 Overview of information events Info number Info name I1000 --------(Device ok) I1079 Sensor changed I1089 Power on I1090 Configuration reset I1091 Configuration changed I11074 Device verification active I1110 Write protection switch changed I11104...
Diagnosis and troubleshooting Micropilot FMR62B HART For details see the "Description of device parameters" documentation. 11.8.2 Resetting the device via keys on the electronic insert Resetting the password 15 s Display 2× A0050210 24 Sequence - resetting the password Deleting/resetting the password 1.
Micropilot FMR62B HART Maintenance For detailed information on the Information submenu: Description of device parameters. 11.10 Firmware history The firmware version can explicitly be ordered via the product structure. This makes it possible to ensure the compatibility of the firmware version with an existing or planned system integration.
Repair concept Endress+Hauser repair concept • The devices have a modular design • Repairs can be carried out by Endress+Hauser Service or by appropriately trained customers • Spare parts are grouped into logical kits with the associated replacement instructions For more information on service and spare parts, please contact your Endress+Hauser sales representative.
Micropilot FMR62B HART Repair 13.3.1 HistoROM It is not necessary to perform a new device calibration after replacing the display or transmitter electronics. The spare part is supplied without HistoROM. After removing the transmitter electronics, remove HistoRom and insert it into the new spare part.
Accessories Micropilot FMR62B HART Accessories The accessories currently available for the product can be selected at www.endress.com: 1. Select the product using the filters and search field. 2. Open the product page. 3. Select Spare parts & Accessories. 14.1 Weather protection cover: 316L, XW112 The weather protection cover can be ordered together with the device via the "Accessory...
Accessories Micropilot FMR62B HART 14.5 Gas-tight feedthrough Chemically inert glass feedthrough, which prevents gases from entering the electronics housing. Can optionally be ordered as "Accessory mounted" via the product structure. 14.6 Commubox FXA195 HART For intrinsically safe HART communication with FieldCare via the USB interface Technical Information TI00404F 14.7...
Micropilot FMR62B HART Accessories 14.12 DeviceCare SFE100 Configuration tool for HART, PROFIBUS and FOUNDATION Fieldbus field devices Technical Information TI01134S 14.13 FieldCare SFE500 FDT-based plant asset management tool It can configure all smart field units in your system and helps you manage them. By using the status information, it is also a simple but effective way of checking their status and condition.
Technical data Micropilot FMR62B HART Technical data 15.1 Input Measured variable The measured variable is the distance between the reference point and the product surface. The level is calculated based on "E", the empty distance entered. Measuring range The measuring range starts at the point where the beam hits the tank floor. Levels below this point cannot be measured, particularly in the case of spherical bases or conical outlets.
Page 65
Micropilot FMR62B HART Technical data 100% A0051658 31 Usable measuring range Length of antenna + 10 mm (0.4 in) Usable measuring range 50 to 80 mm (1.97 to 3.15 in); medium εr < 2 Vessel height Reference point of measurement, varies depending on the antenna system For further information on the reference point, see →...
Page 66
• Relative permittivity (ε value), Compendium CP01076F • The Endress+Hauser "DC Values app" (available for Android and iOS) Measurement in storage vessel Storage vessel - measuring conditions Calm medium surface (e.g. bottom filling, filling via immersion tube or rare filling from...
Page 67
Micropilot FMR62B HART Technical data Antenna, PTFE cladded flush mount, 50 mm (2 in) in storage vessel Media group Measuring range A0 (ε 1.2 to 1.4) 7 m (23 ft) A (ε 1.4 to 1.9) 12 m (39 ft) B (ε...
Page 68
Technical data Micropilot FMR62B HART PTFE Drip-off antenna, 50 mm (2 in) in buffer vessel Media group Measuring range A0 (ε 1.2 to 1.4) 4 m (13 ft) A (ε 1.4 to 1.9) 7 m (23 ft) B (ε 1.9 to 4) 13 m (43 ft) C (ε...
Page 69
Micropilot FMR62B HART Technical data Antenna, horn 316L, 65 mm (2.6 in) in buffer vessel Media group Measuring range A0 (ε 1.2 to 1.4) 11 m (36 ft) A (ε 1.4 to 1.9) 21 m (69 ft) B (ε 1.9 to 4) 40 m (131 ft) C (ε...
Page 70
Technical data Micropilot FMR62B HART Antenna, PTFE cladded flush mount, 80 mm (3 in) in vessel with agitator Media group Measuring range A0 (ε 1.2 to 1.4) 7 m (23 ft) A (ε 1.4 to 1.9) 13 m (43 ft) B (ε...
Micropilot FMR62B HART Technical data Measurement in bypass Bypass process conditions Application in vessels with moving medium surface (e.g. permanent free filling from above, mixing jets). Reduced accuracy can be expected depending on the bypass diameter and quality of the pipe.
Page 72
Technical data Micropilot FMR62B HART Current output 2 offers three operating modes for selection: • 4.0 to 20.5 mA • NAMUR NE 43: 3.8 to 20.5 mA (factory setting) • US mode: 3.9 to 20.8 mA Current output 2 can be assigned to the following device variables: •...
Micropilot FMR62B HART Technical data • Switching delay: User-programmable in the 0 to 100 s range, separate for switch-on point and switch-off point • Scan rate: Corresponds to the measuring cycle • Number of switch cycles: Unlimited The switching output can be assigned to the following device variables: •...
Page 74
Technical data Micropilot FMR62B HART Load 4 to 20 mA passive, HART L max [ ] W 1065 U – 1 .5 V £ L max 23 mA 10.5 A0039232 Power supply 10.5 to 30 VDC Ex i Power supply 10.5 to 35 VDC, for other types of protection and non-certified device versions...
Page 75
Micropilot FMR62B HART Technical data Other linearization tables of up to 32 value pairs can be entered manually. Protocol-specific data HART Manufacturer ID: 17 (0x11{hex}) Device type ID: 0x11C1 Device revision: HART specification: DD version: Device description files (DTM, DD) Information and files available at: •...
Page 77
Micropilot FMR62B HART Technical data In the event of temperature (T ) at the process connection, the permitted ambient temperature (T ) is reduced. The following information only takes functional aspects into consideration. Additional restrictions may apply for certified device versions.
Page 78
Technical data Micropilot FMR62B HART Plastic housing; process temperature –20 to +200 °C (–4 to +392 °F) A0032024 34 Plastic housing; process temperature –20 to +200 °C (–4 to +392 °F) = T : –20 °C (–4 °F) | T : +76 °C (+169 °F) = T...
Page 79
Micropilot FMR62B HART Technical data Restriction to a process temperature of 0 to +150 °C (+32 to +302 °F) with CSA C/US approval and plastic housing A0048826 37 Plastic housing; process temperature 0 to +150 °C (+32 to +302 °F) with CSA C/US approval = T...
Page 80
Technical data Micropilot FMR62B HART Plastic housing; process temperature –40 to +280 °C (–40 to +536 °F) A0032024 40 Plastic housing; process temperature –40 to +280 °C (–40 to +536 °F) = T : –40 °C (–40 °F) | T : +76 °C (+169 °F) = T...
Page 81
Micropilot FMR62B HART Technical data Restriction to a process temperature of 0 to +450 °C (+32 to +842 °F) with CSA C/US approval and plastic housing A0048826 43 Plastic housing; process temperature 0 to +450 °C (+32 to +842 °F) with CSA C/US approval = T...
Page 82
Technical data Micropilot FMR62B HART Plastic housing; process temperature –196 to +200 °C (–320 to +392 °F) A0050248 46 Plastic housing; process temperature –196 to +200 °C (–320 to +392 °F) = T : –196 °C (–320 °F) | T : +76 °C (+169 °F) = T...
Page 83
Micropilot FMR62B HART Technical data Aluminum housing; process temperature –20 to +200 °C (–4 to +392 °F) A0032024 49 Aluminum housing, coated; process temperature –20 to +200 °C (–4 to +392 °F) = T : –20 °C (–4 °F) | T : +79 °C (+174 °F) = T...
Page 84
Technical data Micropilot FMR62B HART Aluminum housing; process temperature –40 to +280 °C (–40 to +536 °F) A0032024 52 Aluminum housing, coated; process temperature –40 to +280 °C (–40 to +536 °F) = T : –40 °C (–40 °F) | T : +79 °C (+174 °F) = T...
Page 85
Micropilot FMR62B HART Technical data Aluminum housing; process temperature –196 to +200 °C (–320 to +392 °F) A0050248 55 Aluminum housing, coated; process temperature –196 to +200 °C (–320 to +392 °F) = T : –196 °C (–320 °F) | T : +79 °C (+174 °F) = T...
Page 86
Technical data Micropilot FMR62B HART 316L housing; process temperature –40 to +150 °C (–40 to +302 °F) A0032024 58 316L housing; process temperature range: –40 to +150 °C (–40 to +302 °F) = T : –40 °C (–40 °F) | T : +77 °C (+171 °F) = T...
Page 87
Micropilot FMR62B HART Technical data 316L housing; process temperature –40 to +450 °C (–40 to +842 °F) A0032024 61 316L housing; process temperature –40 to +450 °C (–40 to +842 °F) = T : –40 °C (–40 °F) | T : +77 °C (+171 °F) = T...
Page 88
Technical data Micropilot FMR62B HART 316L housing, hygiene 316L housing, hygiene; process temperature –20 to +150 °C (–4 to +302 °F) A0032024 64 316L housing, hygiene; process temperature –20 to +150 °C (–4 to +302 °F) = T : –20 °C (–4 °F) | T : +76 °C (+169 °F)
Micropilot FMR62B HART Technical data 316L housing, hygiene; process temperature –40 to +200 °C (–40 to +392 °F) A0032024 67 316L housing, hygiene; process temperature –40 to +200 °C (–40 to +392 °F) = T : –40 °C (–40 °F) | T : +76 °C (+169 °F)
Page 90
Technical data Micropilot FMR62B HART Climate class DIN EN 60068-2-38 (test Z/AD) Installation height as per • Generally up to 2 000 m (6 600 ft) above sea level IEC61010-1 Ed.3 • Over 2 000 m (6 600 ft) under the following conditions: •...
Micropilot FMR62B HART Technical data 15.4 Process Process pressure range WARNING The maximum pressure for the device depends on the lowest-rated component with regard to pressure (components are: process connection, optional mounted parts or accessories). ‣ Only operate the device within the specified limits for the components! ‣...
+100 °C (+212 °F) and flange ≥ DN150/6"/150A. The pressure range may be further restricted in the event of a CRN approval. Dielectric constant For liquids ε ≥ 1.2 Contact Endress+Hauser for applications with lower dielectric constants than indicated. Endress+Hauser...
