Operating menu

Advanced process conditions

Navigation
Description
Selection
Factory setting
Additional information
136
For "Operating mode" = "Level" and "Medium type" = "Solid"
Process property
Very fast > 100 m (333 ft) /h
Fast > 10 m (33 ft) /h
Standard < 10 m (33 ft) /h
Medium < 1 m (3ft) /h
Slow < 0.1 m (0.3ft) /h
No filter / test
For "Operating mode" = "Interface" or "Interface with capacitance"
Process property
Very fast > 10 m (400 in)/min
Fast > 1 m (40 in)/min
Standard < 1 m (40in) /min
Medium < 10 cm (4in) /min
Slow < 1 cm (0.4in) /min
No filter / test
 Setup → Advanced setup → Level → Advanced process conditions
Specify additional process conditions (if required).
• None
• Oil/Water condensate
• Probe near tank bottom
• Build up
• Foam (>5cm/0,16ft)
None
Meaning of the options
• Oil/Water condensate (only Medium type = Liquid)
Makes sure that in the case of two-phase media only the total level is detected (example:
oil/condensate application).
• Probe near tank bottom (only for Medium type = Liquid)
Improves the empty detection, especially if the probe is mounted close to the tank
bottom.
• Build up
Increases EOP range upper area in order to ensure a safe empty-detection even if the
end-of-probe signal has shifted due to build-up.
Enables a safe empty-detection even if the end-of-probe signal has shifted due to build-
up.
• Foam (>5cm/0,16ft) (only for Medium type = Liquid)
Optimizes the signal evaluation in applications with foam formation.
Levelflex FMP50 PROFIBUS PA
Step response time / s
37
37
74
146
290
< 1
Step response time / s
5
5
23
47
81
2.2
