Levelflex FMP50 PROFIBUS PA

Switch output function

Navigation
Description
Selection
Factory setting
Additional information

Assign status

Navigation
Prerequisite
Description
9) Ordering feature 020 "Power supply; Output", option B, E or G
Endress+Hauser
"Switch output" submenu
The Switch output submenu (→  157) is only visible for devices with switch
9)
output.
Navigation  Setup → Advanced setup → Switch output
 Setup → Advanced setup → Switch output → Switch output function
Select function for switch output.
• Off
• On
• Diagnostic behavior
• Limit
• Digital Output
Off
Meaning of the options
• Off
The output is always open (non-conductive).
• On
The output is always closed (conductive).
• Diagnostic behavior
The output is normally closed and is only opened if a diagnostic event is present. The
Assign diagnostic behavior parameter (→  158) determines for which type of event
the output is opened.
• Limit
The output is normally closed and is only opened if a measured variable exceeds or falls
below a defined limit. The limit values are defined by the following parameters:
– Assign limit (→  158)
– Switch-on value (→  159)
– Switch-off value (→  160)
• Digital Output
The switching state of the output tracks the output value of a DI function block. The
function block is selected in the Assign status parameter (→  157).
The Off and On options can be used to simulate the switch output.
 Setup → Advanced setup → Switch output → Assign status
Switch output function (→  157) = Digital Output
Select device status for switch output.
Operating menu


157
